Summary of Contents for Amprobe TMA40
- Page 1 TMA40 Airflow Anemometer Users Manual...
- Page 2 TMA40 Airflow Anemometer Users Manual TMA40_Rev001 © 2008 Amprobe Test Tools. All rights reserved.
- Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 1 SYM. 2 ABC DEF 3 MNO 6 5 JKL 4 GHI 7 PQRS WXYZ 9 8 TUV ON/OFF MEAS: Normal (Single) measurement MEM : Manual record(99 points) measurement LOG : Automatic record (Logger) measurement : Logger, Unit, real time, other setting ➊...
-
Page 5: Table Of Contents
TMA40 Airflow Anemometer CONTENTS introduction ............................5 Unpacking and inspection .........................5 operation ............................5 Meter setting: SeT (See fig.2) .......................5 Meter Screen description (See figs 2&3) ..................5 Single Measurement: MeAS (See fig. 3) ..................6 Multiple Measurement: MeM (See fig. 4) ..................6 Automatic logging: log (See fig. 5) ...................6 Comparison Table ..........................7... -
Page 6: Introduction
4-pcs AAA batteries or 9V adaptor (not included) (plug: outer:5.5mm; inner:2.1mm; Center positive) 0.05mA minimum UNPACKING AND INSPECTION Your shipping carton should include: 1 x TMA40 Airflow Anemometer 4 x AAA battery 1 x RS232 Cable 1 x Cd download Suite... -
Page 7: Single Measurement: Meas (See Fig. 3)
id: press ediT to enter the user id. Use the keypad to enter the information. Note: To calculate air volume, first enter the value of the air source area. Three choices are available: length x width (rectangle); diameter(Circle); and Area. Range from 0~300cm (Rectangle and Circle and 0~90000sq.cm for area. -
Page 8: Comparison Table
• press nexT • press p-pg(previous page) or n-pg (next page) to see the previous or the next 100 points. • press bACK • press exiT to return to the main screen COMPARISON TABLE Measurement Description Memory Point Single point Single point measurement no Memory file name editable... -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS Temperature range -20°C to 70°C (-4°f to 158°f) Temperature accuracy ± 0.6°C (± 1°f) Temperature resolution 0.1°C (0.1°f) Temperature response 30 seconds Relative humidity range 0 to 100% Rh accuracy ± 3% at 10% to 99%; ± 5% at all others Rh resolution 0.1% Rh response time... -
Page 10: Troubleshooting
Select TMA40 and click on “next” Click on “next” and then “next” to download information from the device Click “next”, then “yes”, and then “finish” to complete the downloading Click on “Visualizations” to select measurement table Select the parameters you want to visualize and click oK (See fig.6) NB. - Page 11 Welcome Welcome MEAS MEAS LCD Cont.(1-5): 3 LCD Cont.(1-5): 3 Prn Cont. .(1-9): 5 Prn Cont. .(1-9): 5 Auto Off: 20 mins Auto Off: 20 mins Enable Enable EXIT EDIT NEXT EXIT EDIT NEXT Set Clock: Set Clock: MM-DD-YY HH:MM:SS MM-DD-YY HH:MM:SS 02-28-08 18: 29: 20...
- Page 12 Welcome Welcome MEAS MEAS 001: WBT: WBT: VOL: VOL: NEXT NEXT EDIT START EXIT MEAS EXIT Begin: 02-13-08 Start: 04:25:36 End: 02-25-08 Suspend: 02:44:15 29.7°C 73.7% Rate: 60Sec(s) Expect: 2400Points WBT: VOL: Remain: 2300Points 26.1°C 0.1CMM EXIT EDIT VIEW NEXT ABORT SAVE Press START to begin...
- Page 13 fig.6...
- Page 14 Visit www.Amprobe.com for • Catalog • Application notes • product specifications • User manuals please Recycle...
