Daewoo DLT-19W4 Service Manual

Daewoo DLT-19W4 Service Manual

19”,20”,22” lcd tv, chassis: sl-150t/150p
Hide thumbs

Advertisement

Table of Contents

Service Manual
CHASSIS: SL-150T/150P
Model: DLT-19W4 / DLP-19W4
DLT-22W4 / DLP-22W4
DLT-20J1 / DLP-20J1M
DLT-20J3 / DLP-20J3M
DLT-20J9 / DLP-20J9M
DLT-19L1 / DLP-19L1
DLT-19L2 / DLP-19L2
DLT-22L1 / DLP-22L1
DLT-22L2 / DLP-22L2
Caution:
In this manual some parts can be changed for improving. Their
performance without notice in the parts list. So, if you need the lat-
est parts information, please refer to PPL(Parts Price List) in Service
Information Center.
S/M NO. : DSL150TP00
19",20",22" LCD TV
JAN. 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLT-19W4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DLT-19W4

Summary of Contents for Daewoo DLT-19W4

  • Page 1 S/M NO. : DSL150TP00 Service Manual 19”,20”,22” LCD TV CHASSIS: SL-150T/150P Model: DLT-19W4 / DLP-19W4 DLT-22W4 / DLP-22W4 DLT-20J1 / DLP-20J1M DLT-20J3 / DLP-20J3M DLT-20J9 / DLP-20J9M DLT-19L1 / DLP-19L1 DLT-19L2 / DLP-19L2 DLT-22L1 / DLP-22L1 DLT-22L2 / DLP-22L2 Caution: In this manual some parts can be changed for improving.

  • Page 2: Table Of Contents

    Contents I. Parts with the exception of MODULE 1. Safety Precaution ............2 2.

  • Page 3: Safety Precaution

    1. Safety Precautions When moving or laying down a LCD Set, at least two people must work together. Avoid any impact towards the LCD Set. Do not leave a broken LCD Set on for a long time. To prevent any further damages, after checking the condition of the broken Set, make sure to turn the power (AC) off.

  • Page 4: Product Specification

    2. Product Specifications Model DLT-19W4 / DLP-19W4 DLT-20Jx / DLP-20JxM DLT-22W4 / DLP-22W4 Screen Size 480mm (diagonal) 510.54mm (diagonal) 558.673mm (diagonal) Display Colour 16.7 M Aspect Ratio 16:10 16:10 Resolution 1440 x 900 (WXGA+) 640 x 480 (VGA) 1680 x 1050 (WSXGA+) Pixel Pitch 0.2835 x 0.2835...
  • Page 5 3. Block Diagram (Main) * DLT model only ” ” ”...

  • Page 6: Block Diagram

    Block Diagram (Power Lips)
  • Page 7 4. Schematic Diagram (DLT-19W4, DLT-22W4)
  • Page 8 Schematic Diagram (DLT-20J1, DLT-20J3)

  • Page 9: Schematic Diagram

    Schematic Diagram...
  • Page 10 Schematic Diagram...
  • Page 11 Schematic Diagram...
  • Page 12 Schematic Diagram This page can be used only for DLT models...
  • Page 13 Schematic Diagram...
  • Page 14 Schematic Diagram...
  • Page 15 5. PCB Data (DLT-19W4, DLT-22W4 - TOP)

  • Page 16: Pcb Data

    PCB Data (DLT-19W4, DLT-22W4 - BOTTOM)
  • Page 17 PCB Data (DLT-20J1, DLT-20J3 - TOP)
  • Page 18 PCB Data (DLT-20J1, DLT-20J3 - BOTTOM)
  • Page 19 PCB Data (DLT-19W4, DLT-22W4 - Control PCB - TOP)
  • Page 20 PCB Data (DLT-19W4, DLT-22W4 - Control PCB - BOTTOM)
  • Page 21 PCB Data (DLT-20J1, DLT-20J3 - Control PCB - TOP )
  • Page 22 PCB Data (DLT-20J1, DLT-20J3 - Control PCB - BOTTOM)
  • Page 23 (2) This TROUBLE SHOOTING list only contains representative and simple PCB trouble diagnosis and Module Exchange method. Therefore, if you find Sets which are difficult to diagnose or to repair, contact Daewoo Electronics. (3) Basic TROUBLE SHOOTING procedure : Check Trouble Symptoms Detach Back Cover Trouble Diagnosis Replace broken PCB module Adjust ADC Function Check Repair Complete.

  • Page 24: Trouble Shooting

    Trouble Shooting 6-1. When LED doesn’t lit. Check start Is the AC power cord Confirm power cord correctly connected? connection. Confirm Power S/W ON. Is power S/W ON? Is output voltage of Check the power connection. Power LIPS correct? Exchange the power LIPS. Check the Main PCB.
  • Page 25 Trouble Shooting 6-2. When TV doesn’t turn on in red LED. Check start Does TV turn on Is output voltage of Check the power connection. pushing the CH key? Power module correct? Exchange the Power module. (or LIPS) Check the connection to IR PCB. Confirm Power S/W ON.
  • Page 26 Trouble Shooting 6-4. When “No picture” in TV mode. Check start Go to chap 7 - 2 Does LED turn on in GREEN? Confirm AC connection. Confirm Power SW ON. Does raster appear? Is this weak discharge Check the power, On the screen? Inverter and panel Check I501...
  • Page 27 Trouble Shooting 6-5. When “No picture” in External input mode. Check start Confirm AC connection. Does OSD menu Confirm Power SW ON. Is this weak discharge Screen appear? Check the power, On the screen? Inverter and panel Go to 7 - 4 Is the signal jack Check the Correctly connected?
  • Page 28 Trouble Shooting 6-6. When No Sound in External input mode. Check start Does Screen appear? Go to 7-5 Check the Is the sound input jack Connection of sound Jack Correctly connected? Check the Is the speaker jack Correctly connected? Connection of speaker Check the AUDIO AMP(I601) Is the I601 output And I501...
  • Page 29 Trouble Shooting 6-7. When Key does not operate. Check start Does remote Controller operate? Check the I501 Is 2th PIN of P903A Exchange Key PCB Correctly operate? Check Key cable and I501...
  • Page 30 Trouble Shooting 6-8. When Remote Controller does not operate. Check start Does input of key Check the I501 operate? Does remote Controller operate? Check the battery of remote controller Whenever push the button of Exchange the Key PCB Remote controller, does the 2nd pin Of P506A output normal? Check IR cable and I501 Output of 2nd pin of P501A (IR) : PCB for Remote Control EX) Push “PR DOWN”...

  • Page 31: Service Part List

    7. Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION M201 4852098411 MASK FRONT 19W4 HIPS BK ZZ110 PTACPWG105 ACCESSORY AS DLT-19W4LMBSCF M201A 4857818506 CLOTH BLACK CLOTH 240X8XT0.5 4850Q00910 BATTERY AAA R03 SUPERGARD/ROCKET...
  • Page 32 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION X502 5XJX19R6JE CRYSTAL QUARTZ HC-49/S 19.6608MHZ 18PF C635 CMXL1J334J C MYLAR 63V 0.33MF J MEU TP 30PPM C655 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP...
  • Page 33 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION CA40 HCQK120JBA C CHIP CERA 50V CH 12PF J 1608 CD37 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608 CA41 HCQK120JBA C CHIP CERA...
  • Page 34 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION R550 HRFT000JBA R CHIP 1/10 0 OHM J 1608 RA05 HRFT471JBA R CHIP 1/10 470 OHM J 1608 R551 HRFT000JBA R CHIP 1/10 0 OHM J 1608...
  • Page 35 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION RD26 HRFT103JBA R CHIP 1/10 10K OHM J 1608 C544 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608 RD27 HRFT103JBA R CHIP 1/10 10K OHM J 1608...
  • Page 36 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION CD92 HCELF220MD C CHIP ELECTRO 16V 22MF CM 4052 CA48 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608 CD93 HCEJF100MC C CHIP ELECTRO...
  • Page 37 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION ID07 174LVC162D IC CHIP BUFFER 74LVC16244 L961 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S L962 HFFMMZ400A F CHIP FERRITE BEAD 40 OHM MMZ 2012S...
  • Page 38 Service part list (DLT-19W4) PART CODE PART NAME PART DESCRIPTION PART CODE PART NAME PART DESCRIPTION RA66 HRFT750JBA R CHIP 1/10 75 OHM J 1608 RD54 HRFT473JBA R CHIP 1/10 47K OHM J 1608 RA71 HRFT101JBA R CHIP 1/10 100 OHM J 1608...
  • Page 39 8. Different part list for models Model: DLT-19W4 DLT-22W4 PART CODE PART NAME (PART DESCRIPTION) PART CODE PART NAME (PART DESCRIPTION) 7178301251 SCREW TAPPTITE (TT2 WAS 3X12 MFZN 3CR) 7178301251 SCREW TAPPTITE (TT2 WAS 3X12 MFZN 3CR) A001 4859818992 PCB MAIN (SL-150T 234X189 K4V (WIDE))

  • Page 40: Different Part List For Models

    BUTTON CH (19/22W4 ABS GY340A+SV2405BP) 4854965611 BUTTON CH (19/22W4 ABS GY340A+SV2405BP) M491A M542 M551 M551A M561 48556192SD02 MARK BRAND (DAEWOO 68MM (20”21”)) 48556192SD02 MARK BRAND (DAEWOO 68MM (20”21”)) M591 485594900001 DECO PLATE (19W4 PC T2.0) 485594910001 DECO PLATE (22W4 PC T2.0) M801...
  • Page 41 Different part list for models Model: DLT-20J1 DLT-20J3 PART CODE PART NAME (PART DESCRIPTION) PART CODE PART NAME (PART DESCRIPTION) A001 4859817493 PCB MAIN (SL-150T 234X189 K4V) 4859817493 PCB MAIN (SL-150T 234X189 K4V) A002 4859833814 PCB CONTROL (SL-150T 140 X34(246X330/ 4859833814 PCB CONTROL (SL-150T 140 X34(246X330/2X5)D1B) 2X5)D1B)
  • Page 42 DECO SENSOR (20J3 GPPS MILKY) M551A 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 7178301051 SCREW TAPPTITE (TT2 WAS 3X10 MFZN 3CR) 3CR) M561 48556192SD02 MARK BRAND (DAEWOO 68MM (20”21”)) 48556254SD02 MARK BRAND (SILVER DIA-CUTTING(DOUBLE FACED TYPE)) M591 M801 DMP5031200 BOX (DLT-20J1) DMP5031300 BOX (DLT-20J3)
  • Page 43 Different part list for models Model: DLT-19W4 DLP-19W4 PART CODE PART NAME (PART DESCRIPTION) C671 HCELH100MC C CHIP ELECTRO (25V 10MF CM 4052) C904 HCEEF101MC C CHIP ELECTRO (MV 16V 100MF 6.3DX5.7H) C913 HCBK104KBA C CHIP CERA (50V X7R 0.1MF K 1608)
  • Page 44 Different part list for models Model: DLT-19W4 DLP-19W4 PART CODE PART NAME (PART DESCRIPTION) CD20 HCELF220MD C CHIP ELECTRO (16V 22MF CM 4052) CD21 HCBK104KBA C CHIP CERA (50V X7R 0.1MF K 1608) CD22 HCBK104KBA C CHIP CERA (50V X7R 0.1MF K 1608)
  • Page 45 Different part list for models Model: DLT-19W4 DLP-19W4 PART CODE PART NAME (PART DESCRIPTION) CD68 HCQK270JBA C CHIP CERA (50V CH 27PF J 1608) CD71 HCQK391JBA C CHIP CERA (50V CH 390PF J 1608) CD74 HCELK479MC C CHIP ELECTRO (50V 4.7MF CM 4052)
  • Page 46 Different part list for models Model: DLT-19W4 DLP-19W4 PART CODE PART NAME (PART DESCRIPTION) L922 HLC479J00A L CHIP COIL (4.7UH MLF2012) L923 HLC479J00A L CHIP COIL (4.7UH MLF2012) L971 HLC479J00A L CHIP COIL (4.7UH MLF2012) L973 HLC479J00A L CHIP COIL (4.7UH MLF2012)
  • Page 47 Different part list for models Model: DLT-19W4 DLP-19W4 PART CODE PART NAME (PART DESCRIPTION) RD107 HRFT101JBA R CHIP (1/10 100 OHM J 1608) RD108 HRFT102JBA R CHIP (1/10 1K OHM J 1608) RD109 HRFT102JBA R CHIP (1/10 1K OHM J 1608)
  • Page 48 Different part list for models Model: DLT-19W4 DLP-19W4 PART CODE PART NAME (PART DESCRIPTION) RD43 HRFT201JBA R CHIP (1/10 200 OHM J 1608) RD47 HRFT103JBA R CHIP (1/10 10K OHM J 1608) RD49 HRFT000JBA R CHIP (1/10 0 OHM J 1608)
  • Page 49 9. Electrical Requirements (DLT-19W4, DLT-22W4) Input Requirements Input Voltage Range Voltage Range:AC180V to 270V Normal Voltage: AC 240V Frequency Range Frequency Range: 47 To 63Hz Normal Frequency: 50 To 60Hz Input Current ≤0.5 Arms at 240 Vac input Inrush Current...
  • Page 50 Schematic - Power...
  • Page 51 Schematic - Inverter...

  • Page 52: Electrical Requirements

    Electrical Requirements (DLT-20J1, DLT-20J3) Input Requirements Input Voltage Range Voltage Range: AC180V to 270V / Normal Voltage:AC 240V Frequency Range Frequency Range: 47 To 63Hz Normal Frequency: 50 To 60Hz Input Current ≤0.5 Arms at 240 Vac input Inrush Current 240V 30A peak Earth Leakage Current 3.5mA MAX(250AC)
  • Page 53 Schematic - Power...
  • Page 54 Schematic - Inverter...
  • Page 55 10. DLT/DLP-19W4 Outline...

  • Page 56: Out Line

    DLT/DLP-20J1/J9 Outline...
  • Page 57 DLT/DLP-20J3 Outline...
  • Page 58 DLT/DLP-22W4 Outline...
  • Page 59 11. DLT/DLP-19W4 Exploded View...

  • Page 60: Exploded View

    DLT/DLP-20J1/J9 Exploded View...
  • Page 61 DLT/DLP-20J3 Exploded View...
  • Page 62 DLT/DLP-22W4 Exploded View...
  • Page 63 Connect RS232 upgrade JIG to serial port. (If needed use extention RS232 cable.) c). Turn On computer. 3. Software installation. a). DAEWOO GProbe folder include three files: - CGProbe Redistributable 5.7.0.1.exe, - Readme.txt, - setup.exe. Before install DAEWOO_GProbe application please install first Microsoft .NET Framework and then next CGProbe Redistributable 5.7.0.1 (file: CGProbe Redistributable 5.7.0.1.exe).

  • Page 64: Software Install & Upgrade

    Software Install & Upgrade 4. Software configuration. a). Start application DAEWOO GProbe After start application you need to set Port, Speed, AppsTest (depends on PCB state), Flash image, Flash driver or if you switch on Batch file mode then you need to choose Batch file.
  • Page 65 Software Install & Upgrade d). AppsTest This setting depends on PCB state. When you want to program PCB without sofware, then this option should be OFF (not mark). In case of upgrade software to newer version you need to switch AppsTest option ON. If this option is not corect you will have problem with pro- gramming IC.
  • Page 66 Software Install & Upgrade 5. Chassis SL-150 programming procedure for Genesis IC - PCB part. If you adjust correctly application settings then you need to prepare PCB for programming. Photo below shows normal state of PCB (model 20”). The most important point which can be use for pro- gramming you can find as a marked point from 1 to 4.
  • Page 67 - step 2 - push switch SW1, - step 3 - remove jumper J2. After this 3 steps you don’t need to switch ON (mark) option AppsTest at DAEWOO GProbe application. 6. Chassis SL-150 programming procedure for Genesis IC - application part.
  • Page 68 Software Install & Upgrade b). During programming you will see yellow information window with text about current state and commands results. You can see also progress bar. c). If programming procedure successfully finish then the colour of text window will change to green. As a summary you will see writing time and text „PROGRAMMING SUCCESSFULLY!!! „.
  • Page 69 Software Install & Upgrade 7. Chassis SL-150 - NVM reset procedure. a). Please make instructions from point 5 („Chassis SL-150 programming procedure for Genesis IC - PCB part. ” ) and then please choose „Menu -> Commands -> Terminal1 -> NVRAM Fill” b) New window „Terminal1 NVRAM Fill”...
  • Page 70 8. Remarks. During programming sometimes errors can happend. You will see that when text window in DAEWOO GProbe application change colour to red. There will be also text information where problem appears. Below you can see two examples of errors which can appear during programming procedure.
  • Page 71 Software Install & Upgrade II. Digital software upgrade. 1. Equipment needed for digital software upgrade. a). Software: „Serial download server”. b). Computer with serial port or USB to RS232 converter. c). RS232 upgrade JIG. 2. Hardware. Before start! Please check if your computer has serial port, if not please install converter USB to RS232 a).
  • Page 72 Software Install & Upgrade c). Set serial loader port configuration: Properties -> „Configuration”. 5. Chassis SL-150 programming procedure for Genesis IC - PCB part. If you adjust correctly application settings then you need to prepare PCB for programming. Photo below shows normal state of PCB (model 20”). The most important point, which can be use for programming, you can find as a marked point from 1 to 3.
  • Page 73 Software Install & Upgrade 6. Chassis SL-150 programming procedure for Genesis IC - application part. *First you need to finish operations from point 4 and 5. a). Press „Connection” button on ‚”Serial download server” application. It should appears window “Waiting for STB connection”. Now you need to press jumper SW2 on PCB (PCB photo 3, point 1).

  • Page 74: 13. Svc Keys Function

    13. SVC keys function SVC Key Function Name Description Heat-Run Mode only block remocon key code input ADC Adjust Adjust ADC at each input mode.( Appstest 11 ) VOLUME TEST MIN. MAX. CENTER According to option it will write to one or two EDID Write EEPROM TEST PATTERN...
