Michelangelo
HOOD
Pre-installation and installation manual
KML 435
KML 635
KML 635L
KML 935

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Michelangelo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cuppone Michelangelo

Summary of Contents for Cuppone Michelangelo

  • Page 1 Michelangelo HOOD Pre-installation and installation manual KML 435 KML 635 KML 635L KML 935...

  • Page 2: Table Of Contents

    Michelangelo KML 435 hood technical data | hood + double oven ......9 carefully: it contains important information regarding product Michelangelo KML 435 hood technical data | hood + triple oven ....... 10 assembly and safety regulations. Michelangelo KML 635 hood technical data | hood + single oven ...... 11 Michelangelo KML 635 hood technical data | hood + double oven ....

  • Page 3: Checks Before Purchasing

    2 installation (e.g.: wall construction, replacement of a door with a narrower one, renovations, etc.) do not hamper movements. Ed. 0121 - 70702721 REV04 Michelangelo hood - Installation...
  • Page 4 Checks before purchasing Smoke evacuation (Owner’s inspection) The oven is fitted with an adjustable exhaust in the top to get rid of the steam from the cooking chamber. This steam, together with the one from the door during must be conveyed outside the work phases, through the hood.

  • Page 5: Hood Technical Data

    1200x1400x580mm 1560x1400x580mm 1560x1400x580mm KML 635 [47.24x55.12x22.83 in.] [47.24x55.12x22.83 in.] KML 935 [61.42x55.12x22.83 in.] [61.42x55.12x22.83 in.] 64 kg [141 lb] 68 kg [149,9 lb] 77 kg [169,7 lb] 82 kg [180,7 lb] Ed. 0121 - 70702721 REV04 Michelangelo hood - Installation...

  • Page 6: Michelangelo Hood Technical Data

    Michelangelo hood technical data a Oven supply input B equipotential C Circuit breaker (only for american market) D Hood supply input e Oven smoke exhaust f extraction fan g Hood fume inlet conduit...
  • Page 7 Michelangelo hood technical data Fan technical data Characteristic curves - acoustic features [mmcda] [Pa] : flow in m : static pressure in mmcda and Pa - P: Incoming power in W - sfP: specific power factor in W/m /s (blue curves)

  • Page 8: Michelangelo Kml 435 Hood Technical Data | Hood + Single Oven

    Michelangelo KML 435 hood technical data | hood + single oven 409,5 [16,122] 260 [10,236] 519,5 [20,453] 1189 [46,811] 1551 [61,063] 1217 [47,913] 445 [17,520] 70 [2,756] 1189 [46,811] 78,5 [3,091] 516,5 [20,335] 406,5 [16,004] 70 [2,756] 409,5 [16,122] 260 [10,236]...

  • Page 9: Michelangelo Kml 435 Hood Technical Data | Hood + Double Oven

    Michelangelo KML 435 hood technical data | hood + double oven 409,5 [16,122] 1189 [46,811] 260 [10,236] 519,5 [20,453] 1551 [61,063] 1217 [47,913] 445 [17,520] 70 [2,756] 1189 [46,811] 406,5 [16,004] 516,5 [20,335] 78,5 [3,091] 70 [2,756] 409,5 [16,122] 260 [10,236]...

  • Page 10: Michelangelo Kml 435 Hood Technical Data | Hood + Triple Oven

    Michelangelo KML 435 hood technical data | hood + triple oven 409,5 [16,122] 260 [10,236] 519,5 [20,453] 1189 [46,811] 1551 [61,063] 1217 [47,913] 445 [17,520] 70 [2,756] 1189 [46,811] 78,5 [3,091] 516,5 [20,335] 406,5 [16,004] 70 [2,756] 409,5 [16,122] 260 [10,236]...

  • Page 11: Michelangelo Kml 635 Hood Technical Data | Hood + Single Oven

    Michelangelo KML 635 hood technical data | hood + single oven 1909 [75,157] 1189 [46,811] 409,5 [16,122] 260 [10,236] 519,5 [20,453] 1217 [47,913] 445 [17,520] 70 [2,756] 516,5 [20,335] 406,5 [16,004] 1189 [46,811] 78,5 [3,091] 70 [2,756] 409,5 [16,122] 260 [10,236]...

  • Page 12: Michelangelo Kml 635 Hood Technical Data | Hood + Double Oven

    Michelangelo KML 635 hood technical data | hood + double oven 1189 [46,811] 409,5 [16,122] 260 [10,236] 519,5 [20,453] 1909 [75,157] 1217 [47,913] 445 [17,520] 70 [2,756] 516,5 [20,335] 406,5 [16,004] 1189 [46,811] 78,5 [3,091] 70 [2,756] 409,5 [16,122] 260 [10,236]...

  • Page 13: Michelangelo Kml 635 Hood Technical Data | Hood + Triple Oven

    Michelangelo KML 635 hood technical data | hood + triple oven 1909 [75,157] 409,5 [16,122] 260 [10,236] 519,5 [20,453] 1189 [46,811] 1217 [47,913] 445 [17,520] 70 [2,756] 516,5 [20,335] 406,5 [16,004] 1189 [46,811] 78,5 [3,091] 70 [2,756] 409,5 [16,122] 260 [10,236]...

  • Page 14: Michelangelo Kml 635L Hood Technical Data | Hood + Single Oven

    Michelangelo KML 635L hood technical data | hood + single oven 548,5 [21,594] 300 [11,811] 698,5 [27,500] 1547 [60,906] 1535 [60,435] 1201 [47,282] 428,5 [16,869] 70 [2,756] 1547 [60,906] 78,5 [3,091] 695,5 [27,382] 545,5 [21,476] 70 [2,756] 548,5 [21,594] 300 [11,811]...

  • Page 15: Michelangelo Kml 635L Hood Technical Data | Hood + Double Oven

    Michelangelo KML 635L hood technical data | hood + double oven 1535 [60,435] 548,5 [21,594] 300 [11,811] 698,5 [27,500] 1547 [60,906] 1201 [47,282] 428,5 [16,869] 70 [2,756] 1547 [60,906] 78,5 [3,091] 695,5 [27,382] 545,5 [21,476] 70 [2,756] 548,5 [21,594] 698,5 [27,500]...

  • Page 16: Michelangelo Kml 635L Hood Technical Data | Hood + Triple Oven

    Michelangelo KML 635L hood technical data | hood + triple oven 548,5 [21,594] 300 [11,811] 698,5 [27,500] 1547 [60,906] 1535 [60,435] 1201 [47,282] 428,5 [16,869] 70 [2,756] 1547 [60,906] 78,5 [3,091] 695,5 [27,382] 545,5 [21,476] 70 [2,756] 698,5 [27,500] 548,5 [21,594]...

  • Page 17: Michelangelo Kml 935 Hood Technical Data | Hood + Single Oven

    Michelangelo KML 935 hood technical data | hood + single oven 1893 [74,529] 548,5 [21,594] 300 [11,811] 698,5 [27,500] 1547 [60,906] 1201 [47,282] 428,5 [16,869] 70 [2,756] 695,5 [27,382] 545,5 [21,476] 1547 [60,906] 78,5 [3,091] 70 [2,756] 548,5 [21,594] 300 [11,811]...

  • Page 18: Michelangelo Kml 935 Hood Technical Data | Hood + Double Oven

    Michelangelo KML 935 hood technical data | hood + double oven 1893 [74,529] 548,5 [21,594] 300 [11,811] 698,5 [27,500] 1547 [60,906] 1201 [47,282] 428,5 [16,869] 70 [2,756] 695,5 [27,382] 545,5 [21,476] 1547 [60,906] 78,5 [3,091] 70 [2,756] 548,5 [21,594] 300 [11,811]...

  • Page 19: Michelangelo Kml 935 Hood Technical Data | Hood + Triple Oven

    Michelangelo KML 935 hood technical data | hood + triple oven 548,5 [21,594] 300 [11,811] 698,5 [27,500] 1547 [60,906] 1893 [74,529] 1201 [47,282] 428,5 [16,869] 70 [2,756] 695,5 [27,382] 545,5 [21,476] 1547 [60,906] 78,5 [3,091] 70 [2,756] 548,5 [21,594] 300 [11,811]...

  • Page 20: Installation

    InsTaLLaTIOn Safety instructions Symbols used in the manual and on • Persons not involved with the appliance installation may not pass through or stand in the the labels applied to the machine • read this guide carefully before installing the work area during appliance assembly. appliance, and keep it with care in an accessible Indicates that caution is required when performing • The serial plate provides important technical...

  • Page 21: Transport

    • ventilation: steam suction and exhaust from oven by a KML435ASA5CP 5 differentiated speed motor controlled by a front control panel. serial number fig. 6 Ed. 0121 - 70702721 REV04 Michelangelo hood - Installation...

  • Page 22: Positioning And Connection To The Oven Below

    - e.g. wood). Fig. 8 Open the side compartment of the latter to gain access to the electrical panel. remove the cap on the top of the Michelangelo oven and keep the locknut...
  • Page 23 H07rn-f three-pole cable for sin- gle-phase cabling fig. 10 Installed cable section (UL/CSA version): 16/3 cable uL aWM style 3644 Inserting the filters Fig. 10 Insert the filters as shown in the figure. Ed. 0121 - 70702721 REV04 Michelangelo hood - Installation...

  • Page 24: Wiring Diagrams: Suction Hood / Neutral Hood

    Wiring diagrams (eu version) Suction hood Abbreviation Description Hood motor Motor start capacitor CTrL speed variation board LeDs LeD transformer Installed cable type 3x1 mm silicone cable, H07rn-f three-pole cable for single-phase cabling WAGO 3-way Neutral hood mod. 221 WAGO 3-way mod.
  • Page 25 Hood motor (not supplied) Connector CTrL Control board LeDs LeD transformer Installed cable section: 16/3 cable uL aWM style 3644 16/3 cable UL AWM supply from the oven Style 3644 CTRL Ed. 0121 - 70702721 REV04 Michelangelo hood - Installation...

  • Page 26: Smoke Extraction

    Installation Smoke extraction The oven is fitted with an adjustable exhaust in the top to get rid of the steam from the cooking chamber. This steam, together with the one from the door during the must be conveyed outside work phases, through the hood.

  • Page 27: Pre-Testing And Final Inspection

    Partial reproduction without the Manufacturer's consent is prohibited. Measurements are purely indicative and not binding. The original language used to prepare this manual is english: the Manufacturer is not responsible for any translation/interpretation or print errors. Ed. 0121 - 70702721 REV04 Michelangelo hood - Installation...
  • Page 28 CuPPOne 1963 Cuppone f.lli s.r.l. Via sile, 36 31057 silea (TV) - ITaLY T +39 0422 361143 f +39 0422 360993 info@cuppone.com - www.cuppone.com...
