- Page 1 Giorgione HOOD Pre-installation and installation manual KGR4 KGR6 KGR6L KGR9...
-
Page 2: Table Of Contents
Positioning and connection to the oven below...........18 serial number plate reading .....................19 smoke extraction ........................20 Pre-testing and final inspection ..................21 CuPPOne 1963 Cuppone f.lli s.r.l. Via sile, 36 31057 silea (TV) - ITaLY T +39 0422 361143 f +39 0422 360993 info@cuppone.com - www.cuppone.com... -
Page 3: Checks Before Purchasing
CHeCKs BefORe PuRCHasInG Before purchasing the hood and installing it, check the follow- fig. 1 ing conditions, necessary for the correct installation, operation and maintenance of the hood. Transport (Owner’s inspection) √ Make sure that, on the day when you receive the hood or it is installed: • lifting equipment is available that can handle the appliance safely (check weight and dimensions in the... - Page 4 Checks before purchasing Check with an inspection how to eliminate the fumes and gases of the oven ø200mm ø200mm UNDER-HOOD TYPE √ Make sure that hose and clamps [ø7,87 in.] [ø7,87 in.] not supplied hose and clamps Fig. 3 Fig. 4 not supplied The oven is fitted with a flue in the back to get rid of the steam from the cooking chamber and the flue gas.
-
Page 5: Technical Data
Giorgione KGR435 hood technical data | hood + single oven 1215mm 47,8in 200mm 7,9in 100mm 3,9in 260mm 10,2in 954mm 37,6in 259mm 10,2in 1215mm 47,8in 608mm 23,9in 608mm 23,9in model KGR435 62 kg [136.6 lb] 200mm 7,9in 1320x1370x420 mm KGR435 [51.97x53.94x16.54 in.] 140 kg [308.6 lb] Ed. -
Page 6: Giorgione Kgr435 Hood Technical Data | Hood + Double Oven
Giorgione KGR435 hood technical data | hood + double oven 200mm 7,9in 1215mm 47,8in 100mm 3,9in 1215mm 47,8in 260mm 10,2in 954mm 37,6in 259mm 10,2in 608mm 23,9in 608mm 23,9in 200mm 7,9in... -
Page 7: Giorgione Kgr635 Hood Technical Data | Hood + Single Oven
Giorgione KGR635 hood technical data | hood + single oven 1215mm 47,8in 200mm 7,9in 100mm 3,9in 1215mm 47,8in 260mm 10,2in 1312mm 51,7in 259mm 10,2in 608mm 23,9in 608mm 23,9in model 200mm 7,9in KGR635 67 kg [147.7 lb] 1320x1730x420 mm KGR635 [51.97x68.11x16.54 in.] 158 kg [348.3 lb] Ed. -
Page 8: Giorgione Kgr635 Hood Technical Data | Hood + Double Oven
Giorgione KGR635 hood technical data | hood + double oven 1215mm 47,8in 200mm 7,9in 100mm 3,9in 1215mm 47,8in 260mm 10,2in 1312mm 51,7in 259mm 10,2in 608mm 23,9in 608mm 23,9in 200mm 7,9in... -
Page 9: Giorgione Kgr635L Hood Technical Data | Hood + Single Oven
Giorgione KGR635L hood technical data | hood + single oven 1573mm 61,9in 200mm 7,9in 100mm 3,9in 260mm 10,2in 954mm 37,6in 259mm 10,2in 1573mm 61,9in 787mm 31,0in 787mm 31,0in model KGR635L 73 kg [161 lb] 200mm 7,9in 1680x1370x420 mm KGR635L [66.14x53.94x16.54 in.] 165 kg [363.7 lb] Ed. -
Page 10: Giorgione Kgr635L Hood Technical Data | Hood + Double Oven
Giorgione KGR635L hood technical data | hood + double oven 1573mm 61,9in 200mm 7,9in 100mm 3,9in 260mm 10,2in 954mm 37,6in 259mm 10,2in 1573mm 61,9in 787mm 31,0in 787mm 31,0in 200mm 7,9in... -
Page 11: Giorgione Kgr935 Hood Technical Data | Hood + Single Oven
Giorgione KGR935 hood technical data | hood + single oven 1573mm 61,9in 200mm 7,9in 100mm 3,9in 260mm 10,2in 1312mm 51,7in 259mm 10,2in 1573mm 61,9in 787mm 31,0in 787mm 31,0in model 200mm 7,9in KGR935 80 kg [176.3 lb] 1660x1730x420 mm KGR935 [65.35x68.11x16.54 in.] 190 kg [418.9 lb] Ed. -
Page 12: Giorgione Kgr935 Hood Technical Data | Hood + Double Oven
Giorgione KGR935 hood technical data | hood + double oven 1573mm 61,9in 200mm 7,9in 100mm 3,9in 1573mm 61,9in 260mm 10,2in 1312mm 51,7in 259mm 10,2in 787mm 31,0in 787mm 31,0in 200mm 7,9in... -
Page 13: Installation
InsTaLLaTIOn Safety instructions Symbols used in the manual and on • The serial plate provides important technical information. This is vital in case of a request for the labels applied to the machine • Read this guide carefully before installing the maintenance or repair of the equipment: please appliance, and keep it with care in an accessible Indicates that caution is required when performing... -
Page 14: Transport
Installation Transport fig. 5 fig. 6 Fig. 5 fitted with personal protection equipment, transport the appliance to the installation location. use suitable equipment, capable of dealing with its weight: persons not involved with the appliance installation may not pass through or stand in the work area during the appliance assembly. - Page 15 Installation fig. 8 M5x12 M5x12 M5x12 Ed. 0521 - 70702820 REV00 Giorgione hood - Installation...
- Page 16 Installation fig. 9 M5x12 M5x8...
- Page 17 Installation fig. 10 fig. 11 180° M8x16 M8x16 Turn the hood upside down; the manoeuvre must be carried out by fOuR people equipped with personal protective equip- ment (e.g. gloves and safety shoes) Ed. 0521 - 70702820 REV00 Giorgione hood - Installation...
-
Page 18: Positioning And Connection To The Oven Below
Installation Positioning and connection to the oven below fig. 13 only The hoods can be positioned over a Giorgione Gas oven. assembly must be carried out by a minimum of fOuR people because of the dimensions and minimum distance: weight of the hood. ~ 600 mm [24 in.] Fig. -
Page 19: Serial Number Plate Reading
Installation Serial number plate reading Model Fig. 7 Voltage The serial number is on the back of the appliance. It provides important technical information that is vital in case of a request for maintenance or repair of the appliance: please do not remove, damage or modify it. -
Page 20: Smoke Extraction
Installation Smoke extraction The oven is fitted with a flue in the back to get rid of the steam ø200mm from the cooking chamber and the flue gas. [ø7,87 in.] The gas from the cooking chamber and from the door open- ing can be conveyed outside through the manufacturer’s hood (under-hood type). -
Page 21: Pre-Testing And Final Inspection
Installation Pre-testing and final inspection √ Positioning checks Reference chapter on page... Before delivery to the customer, the hood is checked and test- Preliminary operations Has the protective film been removed from the surfaces? on page ed in the Manufacturer’s factories. Positioning and connection to the Is the equipment perfectly bound to the underlying oven? The “production process check sheet”... - Page 22 CuPPOne 1963 Cuppone f.lli s.r.l. Via sile, 36 31057 silea (TV) - ITaLY T +39 0422 361143 f +39 0422 360993 info@cuppone.com - www.cuppone.com...
