Epoch Design Pacifica Quick Start Manual

1/2
E D
POCH ESIGN
Congratulations on the purchase of your Paci ca Platform Bed. This bed has been crafted to the highest
standards of quality and safety and will give you many years of enjoyment and practical use.
On this insert you will nd a list of the hardware and platform bed parts as well as detailed assembly instructions.
Assembly is quite simple and requires only a at head screwdriver and a Phillips head screwdriver. The use of a power
drill with Phillips head attachment is helpful but not necessary. Assembly will be most easily accomplished if you take
the time to carefully sort the hardware and familiarize yourself with the function of each piece.
If you need assistance with assembly, part replacement or any other matter, please contact the toll-free Epoch
Design Customer Service Team from Monday through Friday, 9 AM-5 PM PST at 1 (800) 589-7990. You may also email
your request or comments to info@epochbydesign.com and a customer service representative will respond.
8x Flat Washers 8x Lock Washers
To connect side To connect side
rails to Headboard
rails to Headboard
& Footboard & Footboard
mm 10 20 30 40
2x Side rails
Connect end boards
TWIN
1x Headboard
1x Footboard
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
, LLC
5472: PM-QU-PB-ES 5474: PM-TW-PB-ES
5476: PM-FU-PB-ES
8x 20 mm bolts
To connect side
rails to Headboard
& Footboard
50 60 70
1x Slat bundle
1x Headboard
1x Footboard
Copyright 2020 Epoch Design™ All rights reserved
Pacifica / Modeno
5477: PM-KI-PB-ES
5475: PM-FU-PB-GR

HARDWARE LIST

50 mm screws
Used to secure
center support
0x TWIN 2x QUEEN
2x FULL 4x KING

BED PARTS

Rest on side rails and supports
mattress (strap side down)
FULL / QUEEN
1x Center support
Used to attach
drop support
5479: PM-QU-PB-GR
5478: PM-KI-PB-GR
Thank you and Enjoy
30 mm slat screws
Used to secure
slats to rails
24x TWIN 39x QUEEN
36x FULL 52x KING
Drop supports
Used to attach center support
0x TWIN 2x QUEEN
1x FULL 4x KING
KING
1x Headboard
2x Center supports
Used to attach
drop support
1x Footboard
24-July-2020
1x Hex key
Used to tighten
bolt hardware
