Epoch Design ParkrosePK-QU-PB-ES Assembly Instructions

1/2
1/2
E D
POCH ESIGN
1 Slide one rail into the grooves of the headboard.
Make sure the slat rail is facing the inside of the bed.
Repeat this process with the other side rail.
Congratulations on the purchase of your Parkrose Platform Bed. This bed has been crafted to the highest
standards of quality and safety and will give you many years of enjoyment and practical use.
On this insert you will nd a list of the hardware and platform bed parts as well as detailed assembly
instructions. Assembly is quite simple and requires only a at head screwdriver and a Phillips head screwdriver. The use
of a power drill with the clutch set to low and a Phillips head attachment is helpful but not necessary. Assembly will be
most easily accomplished if you take the time to carefully sort the hardware and familiarize yourself with the function
of each piece.
If you need assistance with assembly, part replacement or any other matter, please contact the toll-free Epoch
Design Customer Service Team from Monday through Friday, 9 AM-5 PM PST at 1 (800) 589-7990. You may also email
your request or comments to info@epochbydesign.com and a customer service representative will respond.
Then tap the top of the rail ends gently with a rubber mallet to make sure the connections are secure.
Attach the drop support to the
center support by placing the barrel
70 mm bolts
nut into the hole in the side of the
Used to connect drop
drop support. Then insert a 70mm
supports to center supports
bolt through the center support into
1x FULL 1x QUEEN
the barrel nut and tighten with the
4x KING
Hex key provided.
mm 10 20 30
Insert the center support into the
bottom of the brackets. Drive two
15 mm wood screws through the
3
2x Side rails
holes in the side of the headboard
Connect end boards
bracket with a Phillips Head
screwdriver.
Then drive another two wood
screws through the holes in the
opposite side of the footboard bracket
into the end of the center support.
4
1x
Spread the slat bundle (strap side down)
evenly across the side rails.
Use the 30mm wood screws to secure all
slats to the side rails with a Phillips Head
screwdriver.
1x
Center support
Used to attach
drop support
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
Have a question? Need a part ASAP? Call 1-800-589-7990 or email info@epochbydesign.com.
Parkrose Platform Bed
, LLC
5462: PK-QU-PB-ES, 5463: PK-FU-PB-ES,
30 mm slat screws
Used to secure
slats to rails
36x FULL 39x QUEEN
52x KING
40 50 60 70
1x Slat bundle
FULL / QUEEN
Headboard
1x
Footboard
Copyright 2018 Epoch Design™ All rights reserved
5467: PK-KI-PB-ES
HARDWARE LIST
Barrel nuts
Used to secure
70 mm bolts
1x FULL x1 QUEEN
4x KING
BED PARTS
Rest on side rails and supports
mattress
(strap side down)
FULL & QUEEN
1x
Footboard
FULL & QUEEN
©
Next, do the same with
the other end of the
rails into the footboard.
Thank you and Enjoy
15 mm wood screws
Used to secure
center support
1x Hex key
4x FULL 4x QUEEN
8x KING
Drop supports
Used to attach center support
1x FULL 1x QUEEN
4x KING
KING
KING
1x
Headboard
2x
Center supports
Used to attach
drop support
KING
28-Sept-2018
28-Sept-2018
Used to tighten
bolt hardware
