E
D
POCH
ESIGN
Congratulations on the purchase of your Paci ca Platform Bed. This bed has been crafted to the highest
standards of quality and safety and will give you many years of enjoyment and practical use.
On this insert you will nd a list of the hardware and platform bed parts as well as detailed assembly instructions.
Assembly is quite simple and requires only a at head screwdriver and a Phillips head screwdriver. The use of a power
drill with Phillips head attachment is helpful but not necessary. Assembly will be most easily accomplished if you take
the time to carefully sort the hardware and familiarize yourself with the function of each piece.
If you need assistance with assembly, part replacement or any other matter, please contact the toll-free Epoch
Design Customer Service Team from Monday through Friday, 9 AM-5 PM PST at 1 (800) 589-7990. You may also email
your request or comments to info@epochbydesign.com and a customer service representative will respond.
70 mm bolts
Used to connect drop
supports to center supports
0x TWIN
1x QUEEN
1x FULL
4x KING
mm
10
20
30
40
2x Side rails
Connect end boards
TWIN
1x Headboard
1x Footboard
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
, LLC
5472: PM-QU-PB-ES 5474: PM-TW-PB-ES
5476: PM-FU-PB-ES
30 mm slat screws
Used to secure
slats to rails
24x TWIN 39x QUEEN
36x FULL 52x KING
50
60
70
1x Slat bundle
FULL / QUEEN
1x Headboard
1x Footboard
Copyright 2018 Epoch Design™ All rights reserved
Pacifica / Modeno
5477: PM-KI-PB-ES
5475: PM-FU-PB-GR
HARDWARE LIST
Barrel nuts
Used to secure
70 mm bolts
0x TWIN
x1 QUEEN
1x FULL
4x KING
BED PARTS
Rest on side rails and supports
mattress (strap side down)
1x Center support
Used to attach
drop support
5479: PM-QU-PB-GR
5478: PM-KI-PB-GR
Thank you and Enjoy
20 mm wood screws
Used to secure
center support
1x Hex key
0x TWIN
4x QUEEN
4x FULL
8x KING
Drop supports
Used to attach center support
0x TWIN
1x QUEEN
1x FULL
4x KING
KING
1x Headboard
2x Center supports
Used to attach
drop support
1x Footboard
10-Jan-2019
Used to tighten
bolt hardware
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Epoch Design Pacifica 5472
Summary of Contents for Epoch Design Pacifica 5472
- Page 1 1x Headboard 1x Headboard 1x Center support 2x Center supports Used to attach Used to attach drop support drop support 1x Footboard 1x Footboard 1x Footboard HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990 Copyright 2018 Epoch Design™ All rights reserved...
- Page 2 10-Jan-2019 Make sure the slat rail is facing the inside of the bed then slide one rail into the grooves of the headboard . Repeat this process with the other side rail. Next, do the same with the other end of the rails into the footboard Then tap the top of the rail ends gently with a rubber mallet to make sure the connections are secure.
