Congratulations on the purchase of your Quinn Twin over Full Bunk Bed. This bed has been crafted to
the highest standards of quality and safety and will give you many years of enjoyment and practical use.
Your bunk bed can be separated into two individual twin beds if the need arises for alternate
sleeping con gurations.
Since this bed is a natural wood product, there will be variations in color and grain, and minor checking
may occur. This is normal and does not compromise the integrity of your bed. In fact, variation in
character of solid hardwood is integral to the beauty and appeal of hardwood furniture, and
distinguishes it from prefabricated, synthetic and composite materials.
Several basic safety considerations must be adhered to when using this bunk bed.
• Never allow a child under 6 years on upper bunk
• Always use the recommended size mattress or mattress support:
Standard twin 37.5" - 38.5" x 74"-75"(95.3cm - 97.8 x 187.9 cm - 190.5 cm) on upper bed and
53" - 54" x 74 " - 75" (134.6 cm - 137.2 cm x 187.9 cm - 190.5 cm) on lower bed to help reduce
the possibility of entrapment or falls.
• Ensure thickness of mattress does not exceed 9" (22.9 cm) for the upper bed
• Surface of mattress must be at least 5" (12.7 cm) below upper edge of safety rails
• Always use safety rails on both sides of upper bunk
• Do not allow horseplay on or under bed(s) and prohibit jumping on the bed(s)
• Prohibit more than one person on upper bed
• If the bunk will be placed next to a wall, the safety rail that runs the full length of the bed should be placed directly
against the wall to prevent entrapment between the bed and the wall
• Follow the information on the warning labels appearing on the upper bunk end board and on the carton
• Do not remove warning label from bed
• Periodically check and ensure that the safety rails, ladder and other components are in their proper positions,
free from damage, and that all connectors are tight
• Do not use substitute parts
• Contact manufacturer or dealer for replacement parts
• The use of a water or sleep otation mattresses is prohibited
• Keep these instructions for future reference
• Use of a night light may provide added safety for a child using the upper bunk
• STRANGULATION HAZARD- Never attach or hang items to any parts of the bunk bed that are not designed
for use with the bed, including but not limited to hooks, belts or jump ropes
On this insert you will nd a list of the hardware and bunk bed parts, as well as detailed assembly
instructions. Assembly is quite simple, and requires only a at head screwdriver and a Phillips head
screwdriver. The use of a power drill with the clutch set to low and a Phillips head attachment is helpful,
but not necessary. Assembly will be most easily accomplished if you take the time to carefully sort
through the hardware and familiarize yourself with the function of each piece.
If you need assistance with assembly, part replacement, or any other matter, please contact the toll-free
Epoch Design Customer Service Team from Monday through Friday, 9 AM-5PM PST at 1 (800) 589-7990.
You may also email your request or comments to info@epochbydesign.com and a customer service
representative will respond.
Quinn Twin over Full BunkBed
TO HELP PREVENT serious or fatal injury from entrapment or falls:
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
Copyright 2018 Epoch Design™ All rights reserved
5174: QU-TF-BB-WH
5175: QU-TF-BB-ES
©
2-Aug-2018
Thank you and Enjoy
