Zierbügel Endtopf
Decorative bar for muffler
HONDA X-ADV
(2021-)
Artikel Nr.: / Item-no.:
9531
4223
00 01
schwarz/black
INHALT
CONTENTS
1x
Zierbügel Endtopf
1x
Schraubensatz
1x Linsenkopfschraube M6x20
1x Linsenkopfschraube M8x55
1x U-Scheibe Ø8,4
1x U-Scheibe Ø6,4x3mm
1x U-Scheibe Ø6,4
1x Aludistanz Ø8,6xØ6x5
1x
Bar for muffler
1x
Screw kit:
1x Filister head screw M6x20
1x Filister head screw M8x55
1x Washer Ø8,4
1x Washer Ø6,4x3mm
1x Washer Ø6,4
1x Alu spacer Ø8,6xØ6x5
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
Set
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle
zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das
entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut
ist. Anzugsmomente beachten!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined
action, you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts,
the screws should be tightened to the torque specified. This guarantees, that the product is mounted without
tension. Observe the tightening torques of the manufacturer!
VORBEREITUNG
PREPARING
Die Originalschraube der hinteren Endtopfaufhängung sowie die untere Originalschraube der Auspuffblende
entfernen, diese entfallen.
Remove the rear original screw of the exhaust muffler suspension as well as the original lower screw of the
cover. Screws are obosolete.
1
