hepco & becker 4223999 00 01 Manual

Decorative bar for muffler

Advertisement

Zierbügel Endtopf
Decorative bar for muffler
HONDA X-ADV
ab Baujahr 2017 / from date of manufacture 2017
Artikel Nr.: / Item-no.:
999
4223
00 01
schwarz/black
INHALT
CONTENTS
1x
Zierbügel Endtopf
1x
Schraubensatz
1x Linsenkopfschraube M6x20
1x Linsenkopfschraube M8x55
1x U- Scheibe Ø8,4
1x U- Scheibe Ø6,4x3mm
1x U- Scheibe Ø6,4
1x
Bar for muffler
1x
Screw kit:
1x Filister head screw M6x20
1x Filister head screw M8x55
1x Washer Ø8,4
1x Washer Ø6,4x3mm
1x Washer Ø6,4
BENÖTIGTE WERKZEUGE

TOOLS REQUIRED

Set
EINSCHRÄNKUNG

LIMITATION

WICHTIG

IMPORTANT

Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer!
VORBEREITUNG

PREPARING

Die Originalschraube der hinteren Endtopfaufhängung sowie die untere Originalschraube der Auspuffblende
entfernen, diese entfallen.
Remove the rear original screw of the exhaust muffler suspension as well as the original lower screw of the cover.
Screws are obosolete.
Nicht in Mombination mit Kofferträger 653999 00 01 montierbar
Cannot be combined with side carrier 653999 00 01
