hepco & becker 42205460001 Quick Start Manual

Canister cutout set

Advertisement

Kanister Cutout Set / Canister Cutout Set
Moto Guzzi V9 Roamer
ab Baujahr 2016 /
from date of manufacture 2016
Artikel Nr.: / Item-no.:
546
4220
00 01
schwarz/black
Nicht passend für die Bobber Sport. Not suitable for the Bobber Sport.
INHALT
CONTENT
1x 700010537 Kanisterhalter links
1x 700009711 Kanister Cutout
1x
Spanngurt (aus 740012)
1x 700010538 Schraubensatz:
2x Zylinderschraube ISK M8x40
2x U-Scheibe Ø8,4
2x Stahldistanz Ø13xØ9x17 schwarz
4x Antivibrationspad
WICHTIG
IMPORTANT
Beachten Sie die in Ihrem Land geltenden Zulassungsbestimmungen.
Für den Bereich der BRD gilt: Ein Eintrag in die Fahrzeugpapiere ist nicht erforderlich.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie
man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf
das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Moto Guzzi V9 Bobber
ab Baujahr 2016 /
from date of manufacture 2016
Artikel Nr.: / Item-no.:
547
4220
00 01
schwarz/black
1x 700010537 Canister holder left
1x 700009711 Canister Cutout
1x
1x 700010538 Screw kit:
2x Allen screw M8x40
2x Washer Ø8,4
2x Steel spacer Ø13xØ9x17 black
4x Anti-vibration pad
Strap
Kombinierbar mit Sissybar/Gepäckbrücke
Can be combined with Sissybar/Rear rack
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 42205460001 and is the answer not in the manual?

Questions and answers

Summary of Contents for hepco & becker 42205460001

  • Page 1 Kanister Cutout Set / Canister Cutout Set Moto Guzzi V9 Roamer Moto Guzzi V9 Bobber ab Baujahr 2016 / ab Baujahr 2016 / from date of manufacture 2016 from date of manufacture 2016 Artikel Nr.: / Item-no.: Artikel Nr.: / Item-no.: 4220 00 01 4220...
  • Page 2 BENÖTIGTE WERKZEUGE TOOLS REQUIRED VORBEREITUNG PREPARING Die beiden Schrauben im Heckfender links entfernen, diese entfallen. Die Antivibrationspads auf die Kontakt- flächen der Kanister-Rückseite aufkleben. Remove the two screws in the rear fender on the left, these are omitted. Glue the anti-vibration pads onto the contact surfaces of the rear of the canister.
