Leadshine Technology DM542E User Manual

Full digital stepper drive
Hide thumbs Also See for DM542E:
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
For
DM542E
Full Digital Stepper Drive
Version 2.0
©2016 All Rights Reserved
Attention: Please read this manual carefully before using the drive!
11/F, Building A3, Nanshan ipark,NO.1001 Xueyuan Blvd, Nanshan Dist, Shenzhen, China
T: (86)755-26409254
F: (86)755-26402718
Web site:
www.leadshine.com
E-Mail:
sales@leadshine.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM542E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Leadshine Technology DM542E

Summary of Contents for Leadshine Technology DM542E

  • Page 1 User’s Manual DM542E Full Digital Stepper Drive Version 2.0 ©2016 All Rights Reserved Attention: Please read this manual carefully before using the drive! 11/F, Building A3, Nanshan ipark,NO.1001 Xueyuan Blvd, Nanshan Dist, Shenzhen, China T: (86)755-26409254 F: (86)755-26402718 Web site: www.leadshine.com...
  • Page 2 According to Leadshine’s terms and conditions of sales, the user of Leadshine’s products in life support or aircraft applications assumes all risks of such use and indemnifies Leadshine against all damages. ©2016 by Leadshine Technology Company Limited. All Rights Reserved...

  • Page 3: Table Of Contents

    Contents Table of Contents 1. Introductions, Features and Applications........................1 Introductions................................1 Features..................................1 Applications.................................1 2. Specifications.................................. 1 Electrical Specifications (T = 25℃/77℉)......................... 1 Operating Environment and other Specifications.......................2 Mechanical Specifications (unit: mm [1inch=24.5mm])....................2 Elimination of Heat..............................2 3. Pin Assignment and Description............................. 3 Connector P1 Configurations............................3 Connector P2 Configurations............................3 4.

  • Page 4: Introductions, Features And Applications

    1. Introductions, Features and Applications Introductions The DM542E is a fully digital stepper drive developed with advanced DSP control algorithm based on the latest motion control technology. It has achieved a unique level of system smoothness, providing optimal torque and nulls mid-range instability.

  • Page 5: Operating Environment And Other Specifications

    DM542E Full Digital Stepper Drive Manual V2.0 Operating Environment and other Specifications Cooling Natural Cooling or Forced cooling Avoid dust, oil fog and corrosive gases Environment 0℃ － 65℃ Ambient Temperature 40%RH－90%RH Operating Environment Humidity －10℃ － 45℃ Operating Temperature Vibration 10-50Hz / 0.15mm...

  • Page 6: Pin Assignment And Description

    3. Pin Assignment and Description The DM542E has two connectors P1&P2, P1 is for control signals connections, and P2 is for power and motor connections. The following tables are brief descriptions of the two connectors. More detailed descriptions of the pins and related issues are presented in section 4, 5, 9.

  • Page 7: Connections Of 4-Lead Motor

    DM542E Full Digital Stepper Drive Manual V2.0 Drive Controller Controller Drive PUL+ PUL+ PUL- PUL- DIR+ DIR+ DIR- DIR- ENA+ ENABLE ENA+ ENA- ENA- ENABLE Figure 2: Connections to open-collector Figure 3: Connections to PNP signal (common-cathode) signal (common-anode) Connections of 4-lead Motor The 4 lead motors are the least flexible and easy to connect.

  • Page 8: Full Coil Configurations

    DM542E Full Digital Stepper Drive Manual V2.0 Full Coil Configurations The full coil configuration on a six lead motor should be used in applications where higher torque at lower speed is desired. This configuration is also referred to as full copper. In full coil mode, the motors should be run at only 70% of their rated current to prevent overheating.

  • Page 9: Power Supply Selection

    6. Power Supply Selection The DM542E can match medium and small size stepping motors (frame size from NEMA17 to 34) made by Leadshine or other motor manufactures around the world. To achieve good driving performances, it is important to select supply voltage and output current properly.

  • Page 10: Current Settings

    DM542E Full Digital Stepper Drive Manual V2.0 Microstep Steps/rev.(for 1.8°motor) 1600 3200 6400 12800 25600 1000 2000 4000 5000 8000 10000 20000 25000 Current Settings For a given motor, higher drive current will make the motor to output more torque, but at the same time causes more heating in the motor and drive.

  • Page 11: Standstill Current Setting

    DM542E Full Digital Stepper Drive Manual V2.0 Standstill Current Setting SW4 is used for this purpose. OFF meaning that the standstill current is set to be half of the selected dynamic current, and ON meaning that standstill current is set to be the same as the selected dynamic current.

  • Page 12: Sequence Chart Of Control Signals

    DM542E Full Digital Stepper Drive Manual V2.0 10. Sequence Chart of Control Signals In order to avoid some fault operations and deviations, PUL, DIR and ENA should abide by some rules, shown as following diagram: Figure 10: Sequence chart of control signals Remark: t1: ENA must be ahead of DIR by at least 5s.

  • Page 13: Frequently Asked Questions

    DM542E Full Digital Stepper Drive Manual V2.0 12. Frequently Asked Questions In the event that your drive doesn’t operate properly, the first step is to identify whether the problem is electrical or mechanical in nature. The next step is to isolate the system component that is causing the problem. As part of this process you may have to disconnect the individual components that make up your system and verify that they operate independently.

  • Page 14: Appendix

    Twelve Month Limited Warranty Leadshine Technology Co., Ltd. warrants its products against defects in materials and workmanship for a period of 12 months from shipment out of factory. During the warranty period, Leadshine will either, at its option, repair or replace products which proved to be defective.

  • Page 15: Contact Us

    DM542E Full Digital Stepper Drive Manual V2.0 Contact Us China Headquarters Address: 11/F, Building A3 , Nanshan iPark, No.1001Xueyuan Blvd, Nanshan District Shenzhen, China Web: http://www.leadshine.com Sales Hot Line: Tel: 86-755-2643 4369 (for All) 86-755-2641-7674 (for Asia, Australia, Africa areas)
