RZ/N1D Group
CONNECT IT! ETHERNET RZ/N1D-DB
Introduction
RZ/N1 is a family of scalable ARM® based industrial Ethernet switches. Due to the integrated performant
ARM® Cortex®-A7 CPU, they are ideal choice for building products such as Programmable Logic Controllers
(PLC), complex remote-IO slaves, industrial switches, gateways or operator terminals.
RZ/N1 Family consists of three devices, out of which the RZ/N1D, is an industrial ethernet communication
System on Chip with 5-ports, in a 400BGA package.
This guide shall assist you to quickly start with your evaluation of the RZ/N1D device on the related Solution
Kit board(s) and the Solution Kit software and documentation. It represents a short guide for the first time users
with the instructions for the first startup of the board.
In addition to this document, please be aware of the extensive documentation on RZ/N1 devices, evaluation
boards and software that you may find in the Solution Kit Documentation directory.
The Solution Kit boards can solely be used for evaluation purposes. It is not allowed to use the boards for
commercial purposes.
List of reference documents
Document name
User's Manual: System Introduction, Multiplexing, Electrical and Mechanical Information
User's Manual: System Control and Peripheral
User's Manual: Peripherals
User's Manual: R-IN Engine and Ethernet Peripherals
User's Manual: Generic Open Abstraction Layer
RZ/N1D Development Board Schematic
RZ/N1D Development Board Setup Notes
RZ/N1 U-Boot User Manual
RZ/N1 Linux User Manual
R01QS0022ED0060 Rev. 0.60
Jan.31.2020
Quick Start Guide
Page 1 of 29
