- Page 1 Grandstream Networks, Inc. GXV3601 User Manual...
- Page 2 The average life time varies from the differences between operating environments and usage history. Regular maintenance checks are recommended for all users. Please contact your dealer for more details. Firmware 1.0.4.6 Page 2 of 37 Grandstream Networks, Inc. 09/2010...
-
Page 3: Table Of Contents
GXV3601 FTP Page ..........................26 GXV3601 PTZ Page ..........................26 GXV3601 Alarm Event......................... 27 GXV3601 Motion Detection ......................... 30 GXV3601 System Log .......................... 32 FAQ ................................33 Firmware 1.0.4.6 Page 3 of 37 Grandstream Networks, Inc. 09/2010... -
Page 4: Welcome
The GXV3601 is a powerful solution for small to medium sized offices, homes and storage facilities looking to safeguard their valuables. Firmware 1.0.4.6 Page 4 of 37 Grandstream Networks, Inc. 09/2010... -
Page 5: Package Contents
6-pin terminal block connector – 6-pin connector block for connecting external devices, such as infrared detector, smoke detector and etc., to Alarm IN, Alarm OUT and RS485 pins. • Quick installation guide Firmware 1.0.4.6 Page 5 of 37 Grandstream Networks, Inc. 09/2010... -
Page 6: Product Overview
GXV3601 IP Camera Product Overview GXV3601 Overview 1: GXV3601 P ABLE RODUCT ODELS Model GXV3601-N xxx-xx004-xxx xxx-xx009-xxx GXV3601-HD GXV3601-LL xxx-xx0011-xxx GXV3601 Side View- (This is only applicable on GXV3601-N) Firmware 1.0.4.6 Page 6 of 37 Grandstream Networks, Inc. 09/2010... -
Page 7: Gxv3601 Back Panel
RESET – Press the Reset button for 6 seconds to perform a factory reset. PINs – 1 PTZ connector, Alarm In connector, and Alarm out connector. USB – USB connector for USB flash/hard drives. Firmware 1.0.4.6 Page 7 of 37 Grandstream Networks, Inc. 09/2010... -
Page 8: Gxv3601 Sample Connection Diagram
Video Compression Max Video Full D1: 704 x 576(PAL) 1,600 x 1,200 640x480 (VGA), Resolution 704 x 480 (NTSC) 320x240 (QVGA), 720x480 (NTSC D1), 352x240 (NTSC CIF), 176x112 (NTSC QCIF); Firmware 1.0.4.6 Page 8 of 37 Grandstream Networks, Inc. 09/2010... - Page 9 Temperature / 0°C – 45°C(32°F–133°F) 0°C – 45°C (32°F–133°F) 0°C – 45°C(32°F–133°F) Humidity Humidity 10–90% RH Humidity 10–90% RH Humidity 10–90% RH (non–condensing) (non–condensing) (non–condensing) Power Output: 12VDC/1.5A; Input: 100–240VAC, 50–60Hz Firmware 1.0.4.6 Page 9 of 37 Grandstream Networks, Inc. 09/2010...
-
Page 10: Gxv3601 Lens Specification
Length 1 x Length Weight 95 g (3.35 oz) 101g 101g Operation Focus (w/lock) Focus (w/lock) Focus (w/lock) Zoom (w/lock) Zoom (w/lock) Zoom (w/lock) Figure1: Lens Specifications for GXV3601-HD and GXV3601-LL Firmware 1.0.4.6 Page 10 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 11: Gxv3601 Recommended Lens Specification
Automatic Aperture lens can be used Angle of View Normal Angle to 90 Wide angle > 90 Infrared Filter According to the actual need, IR lens or Lens with IR-light-compatible might be needed Firmware 1.0.4.6 Page 11 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 12: Minimum Recommended System Requirement
If you are going to connect the device to a hub/switch/router, please use a NOTE: straight-through cable. A cross over cable should be used if you are going to connect the device directly to a PC. Firmware 1.0.4.6 Page 12 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 13: Configuring The Gxv3601 Via Web Browser
8. The default user name and password are both set to admin. 9. IE will indicate that “This website wants to install the following add-on: ‘GSViewerX.cab’ from ‘Grandstream Networks Inc’.” Install this add-on by following the instructions in IE. 10. You will see the home page. -
Page 14: Connect To The Camera Using Static Ip
7. The default user name and password are both set to admin. 8. IE will indicate that “This website wants to install the following add-on: ‘GSViewerX.cab’ from ‘Grandstream Networks Inc’.” Install this add-on by following the instructions in IE. 9. You will see the home page. -
Page 15: Gxv3601 Home Web Page
GXV3601 IP Camera GXV3601 Home Web Page Figure2: Home web page of GXV3601-N and GXV3601-LL Figure3: Home web page of GXV3601-HD Firmware 1.0.4.6 Page 15 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 16: Gxv3601 System Page
(24h clock). Set the System Time Update via NTP Server - the camera will obtain the time from an NTP server Specify the NTP server's IP address or Firmware 1.0.4.6 Page 16 of 36 Grandstream Networks, Inc. 09/2010... -
Page 17: Gxv3601 Video & Audio Page
On Screen Display (OSD) Settings OSD Time/ Text – The time stamp and channel name displayed on the screen. Video Settings Preferred Video Codec – The GXV3601 supports the H.264 video codec. Firmware 1.0.4.6 Page 17 of 3 7 Grandstream Networks, Inc. 09/2010... - Page 18 Preferred Audio Codec – The GXV3601 supports up to 3 different Vocoder types, a-law (PCMA), u-law (PCMU) and G.726. The audio can also be turned off by switching the setting to “Disabled” Audio Compression – Audio Firmware 1.0.4.6 Page 18 of 36 Grandstream Networks, Inc. 09/2010...
-
Page 19: Gxv3601 Networking Page - Assign An Ip To Gxv3601
1. The GXV3601 can obtain the DNS server automatically 2. Users can configure their own preferred DNS server HTTP Port The GXV3601 supports user configured http ports. If the HTTP port is changed, the Firmware 1.0.4.6 Page 19 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 20: Gxv3601 Wifi Page - Gxv3601 Supports Wifi Via Wireless Dongles
Self-Define DDNS Address – Self-define the DDNS server instead of using DDNS ISP Type. Site Name – The DDNS name for your device. DDNS Account/ DDNS Password – The account and password from the DDNS Provider. Firmware 1.0.4.6 Page 20 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 21: Gxv3601 Sip Page
It can be identical to or different from the SIP User ID. Authenticate Password – The SIP service subscriber’s account password for the GXV to register to the SIP server of the ITSP. Firmware 1.0.4.6 Page 21 of 3 7 Grandstream Networks, Inc. 09/2010... - Page 22 3. Enter the Phone number and name, click Add a Number to save all the changes. 4. Numbers added to the system will be listed in this page. Available phone numbers Firmware 1.0.4.6 Page 22 of 3 7 Grandstream Networks, Inc. 09/2010...
-
Page 23: Gxv3601 Status Page
DDNS. Camera Type This section shows the Lens information of GXV3601. The Lens type information contains the brand name, the size of image sensor, the resolution and so on. Firmware 1.0.4.6 Page 23 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 24: Gxv3601 User Management Page
(the location of the firmware files) . Automatic Upgrade Interval – Enter the frequency (in minutes) in which the HTTP/HTTPS/TFTP server will be checked for new firmware upgrades or configuration changes. Firmware 1.0.4.6 Page 24 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 25: Gxv3601 Smtp Page
You can have up to 3 emails configured. User Name/ Password – The user name and password required to log in to your SMTP server, for example, 123@gmail.com/123. Firmware 1.0.4.6 Page 25 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 26: Gxv3601 Ftp Page
Pelco-D and Pelco-P. Select the protocol your PTZ equipment supports. PTZ Baudrate – The Baud rate is the number of distinct symbol changes (signaling events) made to the transmission medium Firmware 1.0.4.6 Page 26 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 27: Gxv3601 Alarm Event
The detectable signal voltage range for alarm-in is from 1.8V to 15 V Please do not connect a device that has a signal voltage that is higher NOTE: Firmware 1.0.4.6 Page 27 of 3 7 Grandstream Networks, Inc. 09/2010... - Page 28 GXV3601 will record the video when an alarm is triggered. You can enter the length of the video recording (in seconds). You can also choose the storage method for video Firmware 1.0.4.6 Page 28 of 3 7 Grandstream Networks, Inc. 09/2010...
- Page 29 To delete a schedule, check the schedule you would like to remove and click Delete. How to connect an Alarm Output Equipment to GXV3601 Here is a sample connection diagram. Connect the alarm output equipment to the GXV3601 by following the diagram below. Firmware 1.0.4.6 Page 29 of 3 7 Grandstream Networks, Inc. 09/2010...
-
Page 30: Gxv3601 Motion Detection
The white border for Motion Detection Regions NOTE: If Upload to Alarm center is checked for Alarm Actions, the white border will flash red when a motion detection alarm is triggered. Firmware 1.0.4.6 Page 30 of 3 7 Grandstream Networks, Inc. 09/2010... - Page 31 The GXV3601 not only can monitor your settings but also can take actions when the alarm is triggered. Monitored region Dropdown list for date Available time schedules Firmware 1.0.4.6 Page 31 of 3 7 Grandstream Networks, Inc. 09/2010...
-
Page 32: Gxv3601 System Log
Video List – This section displays the name, source storage and size of the video files on the connected storage devices. You can view, download or delete the stored files. Firmware 1.0.4.6 Page 32 of 3 7 Grandstream Networks, Inc. 09/2010... -
Page 33: Faq
To enable compatibility view, open IE8, click Tools, Compatibility View Setting, and add the GXV3501/ 3504/ 3601 web configuration pages to the Compatibility View. Firmware 1.0.4.6 Page 33 of 3 7 Grandstream Networks, Inc. 09/2010... - Page 34 It is better to save video files in different directories when using GSurf and GS_NVR in the event that they automatically delete files that you might want to keep. 13. How can I use a cell phone to watch the GXV3501/ 3504/ 3601 video stream? Firmware 1.0.4.6 Page 34 of 3 7 Grandstream Networks, Inc. 09/2010...
- Page 35 If the web port is 80, then the RTSP port is 554. If the web port is not 80, then the RTSP port equals the web port +2000. For example, if the web port is 88, then the RTSP port will be 2088. Firmware 1.0.4.6 Page 35 of 3 7 Grandstream Networks, Inc. 09/2010...
- Page 36 Mobile Intel® 945GM Express Chipset Family Works normally Mobile intel® 915GM/GMS, 910GML Express Chipset Works normally Family Intel® G45/G43 Express Chipset Works normally ATI Technologies, RAGE XL PCI This display adapter cannot display videos. Firmware 1.0.4.6 Page 36 of 3 7 Grandstream Networks, Inc. 09/2010...
- Page 37 —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Firmware 1.0.4.6 Page 37 of 37 Grandstream Networks, Inc. 09/2010...
