Sauder Harbor View 415802 Manual

Multi-purpose stand
Hide thumbs

Advertisement

Quick Links

Download this manual
415802
Multi-Purpose Stand
Harbor View Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-21
Français ...............Pages 22-24
Made in the USA
Espanol .............Páginas 25-27
Archbold, OH
Lot #: 355540
Date Purchased: ____________________
08 / 26 / 13

Advertisement

loading

Related Manuals for Sauder Harbor View 415802

Summary of Contents for Sauder Harbor View 415802

  • Page 1 PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-21 YOUR UNIT TO THE STORE Français ....Pages 22-24 Made in the USA 1-800-523-3987 Espanol .....Páginas 25-27 Archbold, OH www.sauder.com Lot #: 355540 08 / 26 / 13 Date Purchased: ____________________...
  • Page 2 ADULT ASSEMBLY REQUIRED Part Identifi cation .......3 Hardware Identifi cation .....4 ASSEMBLY TOOLS REQUIRED Assembly Steps ....5-21 No. 2 Phillips Screwdriver Français ......22-24 Tip Shown Actual Size Espanol ....... 25-27 Safety ......... 28-30 Hammer Warranty ........31 Page 2 www.sauder.com/services 415802...

  • Page 3: Part Identification

    SHELF SKIRT BACK DRAWER FRONT BOTTOM LONG DIVIDER FRONT TOP MOLDING RIGHT DRAWER SIDE SHORT DIVIDER RIGHT TOP MOLDING LEFT DRAWER SIDE RIGHT FRONT LEG LEFT TOP MOLDING DRAWER BACK LEFT FRONT LEG SHELF MOLDING D719 415802 www.sauder.com/services Page 3...

  • Page 4: Hardware Identification

    SILVER 5/8" MACHINE SCREW - 2 BLACK 2-1/4" FLAT HEAD SCREW - 6 BLACK 1-9/16" FLAT HEAD SCREW - 4 SILVER 1-1/8" FLAT HEAD SCREW - 6 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 415802...
  • Page 5 Look for this icon. It means a video assembly tip is available at: www.sauder.com/services/tips Do not tighten the HIDDEN CAMS in this step. Arrow (12 used) (20 used) Do not insert CAM DOWELS into these edges. Do not insert CAM DOWELS into this edge.
  • Page 6 Turn eight CAM SCREWS (8F) into the LEGS (I and J) and SHELF MOLDING (Q). Page 6 www.sauder.com/services 415802...
  • Page 7 Fasten the BACK LEGS (K) to the ENDS (A and B). Use six BLACK 2-1/4" FLAT HEAD SCREWS (26S). NOTE: Be sure the center holes in the LEGS (K) line up before fastening the LEGS to the ENDS (A and B). 415802 www.sauder.com/services Page 7...
  • Page 8 (4 used for the CABINET RIGHT and LEFT) Fasten a CABINET RIGHT (35GA) to the RIGHT END (A) and a CABINET LEFT (35GB) to the LEFT END (B). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. Page 8 www.sauder.com/services 415802...
  • Page 9 Use your hammer to tap the MOLDING CONNECTOR (19F) into the notches in the MOLDINGS. Flat end Flat end Tap two MOLDING CONNECTORS (19F) into the notches in the MOLDINGS (N, O, and P). 415802 www.sauder.com/services Page 9...
  • Page 10 SILVER 1-1/8" FLAT HEAD SCREW (6 used in this step) Flat edge Fasten the MOLDINGS (N, O, and P) to the TOP (C). Use six SILVER 1-1/8" FLAT HEAD SCREWS (10S). Page 10 www.sauder.com/services 415802...
  • Page 11 Tighten Arrow Risk of damage or injury. Hidden Cams must be completely Arrow Maximum tightened. Hidden 210 degrees Cams that are not completely tightened Minimum may loosen, and parts 190 degrees may separate. To completely tighten: 415802 www.sauder.com/services Page 11...
  • Page 12 S u r H I D Maximum Arrow 210 degrees Minimum 190 degrees Fasten the RIGHT END (A) to the SHELF (E) and BOTTOM (D). Tighten four HIDDEN CAMS. Page 12 www.sauder.com/services 415802...
  • Page 13 Rounded edge Maximum Arrow 210 degrees Minimum 190 degrees Fasten the TOP MOLDINGS (O and P) on the TOP (C) to the ENDS (A and B). Tighten four HIDDEN CAMS. 415802 www.sauder.com/services Page 13...
  • Page 14 NOTE: Be sure the edges of the ANGLE BRACKETS are even with the edges of the SKIRT. Fasten the SKIRT (L) to the ENDS (A and B) and BOTTOM (D). Use three BLACK 9/16" LARGE HEAD SCREWS (1S). Page 14 www.sauder.com/services 415802...
  • Page 15 NOTE: Be sure to tap NAILS into the holes that line up over the SHELF (E). Using your hammer, gently tap four TACK GLIDES (12E) into the bottom edge of the LEGS (I, J, and K). 415802 www.sauder.com/services Page 15...
  • Page 16 Push a CAM COVER (12P) onto each visible HIDDEN CAM. NOTE: Do not put CAM COVERS on the HIDDEN CAMS on the bottom front edge of the SHELF (E). These HIDDEN CAMS will be tightened in the next step. Page 16 www.sauder.com/services 415802...
  • Page 17 SHORT DIVIDER (H) onto the LONG METAL PINS in the SHORT DIVIDER. Now, insert the DIVIDERS (G and H) into the opening as shown. Then, fasten the SHELF MOLDING (Q) to the SHELF (E). Tighten two HIDDEN CAMS. Push two CAM COVERS (12P) onto these HIDDEN CAMS. 415802 www.sauder.com/services Page 17...
  • Page 18 Fasten the DRAWER BACK (D70) to the DRAWER SIDES (D24 and D25). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). NOTE: Be sure the DRAWER BOTTOM (D719) inserts into the groove of the DRAWER BACK (D70). Page 18 www.sauder.com/services 415802...
  • Page 19 SIDE (D25). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. NOTE: The screw head in the CAM must be visible through the slotted hole in the SLIDE. Fasten the PULL (98K) to the DRAWER FRONT (M). Use two SILVER 5/8" MACHINE SCREWS (15S). 415802 www.sauder.com/services Page 19...
  • Page 20 To insert the drawer into your unit, tip the front of the drawer down and drop the rollers on the drawer behind the rollers on the unit. Lift the front of the drawer up and slide it into the unit. Page 20 www.sauder.com/services 415802...
  • Page 21 Tighten the SCREW when finished with adjustments. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. To clean your unit, dampen a cloth with tap water and wipe. 415802 www.sauder.com/services Page 21...

  • Page 22: Liste De Pièces

    DEVANT DE TIROIR ......1 VIS TÊTE PLATE 8 mm DORÉE ..8 pour future référence. Pour contacter Sauder MOULURE DE DESSUS AVANT ..1 15S VIS À MÉTAUX 16 mm ARGENT ..2 en ce qui concerne cet MOULURE DE DESSUS DROITE ...1 26S VIS TÊTE PLATE 57 mm NOIRE ..6...
  • Page 23 Fixer la PLINTHE (L) aux EXTRÉMITÉS (A et B) et au DESSOUS (D). Utiliser trois VIS TÊTE LARGE ÉTAPE 5 14 mm NOIRES (1S). Enfoncer deux CONNECTEURS DE MOULURE (19F) dans les crans des MOULURES (N, O et P). 415802 www.sauder.com/services Page 23...
  • Page 24 3 Fixer l'ARRIÈRE DE TIROIR (D70) aux CÔTÉS DE TIROIR (D24 et D25). Utiliser quatre VIS TÊTE PLATE 40 mm NOIRES (30S). REMARQUE : S'assurer que le FOND DE TIROIR (D719) s'encastre dans la rainure de l'ARRIÈRE DE TIROIR (D70). Page 24 www.sauder.com/services 415802...

  • Page 25: Lista De Partes

    MOLDURA DELANTERA TORNILLO DORADO DE en contacto con DE PANEL SUPERIOR ....1 CABEZA PERDIDA de 8 mm ...8 Sauder en cuanto a MOLDURA DERECHA esta unidad, refi érase 15S TORNILLO PLATEADO PARA DE PANEL SUPERIOR ....1 al número de lote y METAL de 16 mm ......2...
  • Page 26 NOTA: Asegúrese de clavar ligeramente los CLAVOS dentro de los agujeros que se alinean sobre el ESTANTE (E). Con un martillo, suavemente introduzca golpeando cuatro TACHUELAS DESLIZANTES (12E) en el borde de la parte inferior de las PATAS (I, J y K). Page 26 www.sauder.com/services 415802...
  • Page 27 NOTA: La cabeza de tornillo del EXCÉNTRICO debe ser visible a través del agujero alargado de la CORREDERA. Fije el TIRADOR (98K) a la CARA DE CAJÓN (M). Utilice dos TORNILLOS PLATEADOS PARA METAL de 16 mm (15S). 415802 www.sauder.com/services Page 27...
  • Page 28 • Physical injury. Furniture can be very • Do not push furniture, especially on a heavy. carpeted fl oor. Have a friend help you lift the unit and set it in place. • This unit must be positioned against a wall. Page 28 www.sauder.com/services 415802...
  • Page 29 • Ne pas pousser le meuble, surtout sur la moquette. Se faire aider par une autre personne pour soulever l'élément et le mettre en place. • Cet élément devait être placé contre un mur. 415802 www.sauder.com/services Page 29...
  • Page 30 • No empuje la unidad, especialmente ser muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona para levantar la unidad y colocarla en lugar. • Esta unidad debe ser colocada contra una pared. Page 30 www.sauder.com/services 415802...

  • Page 31: Year Limited Warranty

    4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 32 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product identifi ed by this Instruction Book. the item you have purchased is made with 2.
