sauder.com
Storage Cabinet
Harbor View Collection | Model 416797
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Store behind
closed doors.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-17
Español pg 18-20
Lot # 362067
06/04/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Related Manuals for Sauder Harbor View 416797
Summary of Contents for Sauder Harbor View 416797
- Page 1 Harbor View Collection | Model 416797 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
- Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-15 Hammer Not actual size Français 16-17 Español 18-20 Skip the power trip. Safety 21-22 This time. Warranty Page 2 416797 www.sauder.com/services...
- Page 3 RIGHT END (1) BOTTOM (1) SKIRT (1) LEFT END (1) BACK (1) FRONT MOLDING (1) UPRIGHT (1) RIGHT DOOR (1) RIGHT MOLDING (1) TOP (1) LEFT DOOR (1) LEFT MOLDING (1) SHELF (1) ADJUSTABLE SHELF (4) www.sauder.com/services 416797 Page 3...
- Page 4 METAL PIN - 16 BLACK 9/16" LARGE HEAD SCREW - 9 BLACK 1-7/8" FLAT HEAD SCREW - 3 BLACK 1-1/8" PAN HEAD SCREW - 2 BLACK 1/2" FLAT HEAD SCREW - 8 SILVER 2" FLAT HEAD SCREW - 7 Page 4 416797 www.sauder.com/services...
- Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push fourteen HIDDEN CAMS (1F) into the ENDS (A and B), å...
- Page 6 å in the MOLDINGS (L, M, and N). Use your hammer to tap the MOLDING CONNECTORS (18F) into the notches in the MOLDINGS. Flat end Flat end Unfi nished surface Unfi nished surface Unfi nished surface Page 6 416797 www.sauder.com/services...
- Page 7 MOLDINGS to the TOP (D). Use seven SILVER 2" FLAT Remember: HEAD SCREWS (57S). Righty tighty. Lefty loosey. NOTE: Do not overtighten the SCREWS in this step. å SILVER 2" FLAT HEAD SCREW (7 used in this step) Curved edge Curved edge Rounded edge www.sauder.com/services 416797 Page 7...
- Page 8 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 8 416797 www.sauder.com/services...
- Page 9 S u r D E N w i t h H I D H I D D E N Maximum Arrow 210 degrees Minimum 190 degrees BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) www.sauder.com/services 416797 Page 9...
- Page 10 Fasten the SKIRT (K) to the ENDS (A and B) and BOTTOM (F). å Use four 9/16" LARGE HEAD SCREWS (1S) through the METAL BRACKETS and into the SKIRT. BLACK 9/16" LARGE HEAD SCREW (8 used in this step) Curved edge Page 10 416797 www.sauder.com/services...
- Page 11 NOTE: Be sure to tap NAILS into the holes that line up å over the UPRIGHT (C) and SHELF (E). NAIL (51 used in this step) These holes must line up over the UPRIGHT (C) and SHELF (E). www.sauder.com/services 416797 Page 11...
- Page 12 Step 8 Fasten the HINGES (13H) to the DOORS (H and I). Use å eight BLACK 1/2" FLAT HEAD SCREWS (11S). BLACK 1/2" FLAT HEAD SCREW (8 used in this step) Page 12 416797 www.sauder.com/services...
- Page 13 FELT DISC on the DOOR where it comes in contact with Hinge the SHELF (E). Repeat this step for the RIGHT DOOR (H). å BLACK 1-1/8" PAN HEAD SCREW (2 used in this step) Want options? Customize your item with add-on hardware kits available on sauder.com. www.sauder.com/services 416797 Page 13...
- Page 14 To adjust the DOORS in or out (depth), loosen the mounting screw one å turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 14 416797 www.sauder.com/services...
- Page 15 (1 used into a stud in your wall) 10 lbs. BLACK 9/16" LARGE HEAD SCREW (1 used into the top of your unit) 50 lbs. 25 lbs. 25 lbs. 25 lbs. 25 lbs. 60 lbs. total (16 used) www.sauder.com/services 416797 Page 15...
- Page 16 QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 EXCENTRIQUE ESCAMOTABLE ....14 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 CHEVILLE D'EXCENTRIQUE ......14 en ce qui concerne cet MONTANT................1 18F CONNECTEUR DE MOULURE......2 élément, faire référence au numéro de lot et...
- Page 17 Avec précaution, retourner l'élément sur ses chants avant. Déplier l'ARRIÈRE (G) et le placer sur l'élément. les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 416797 Page 17...
- Page 18 EXCÉNTRICO ESCONDIDO ......14 et conserver le livret pour future référence. EXTREMO IZQUIERDO ............1 PASADOR DE EXCÉNTRICO ......14 Pour contacter Sauder PARAL ....................1 18F CONECTOR DE MOLDURA ........2 en ce qui concerne cet MÉNSULA DE SEGURIDAD .........1 PANEL SUPERIOR ..............1 élément, faire référence...
- Page 19 Fije el DORSO (G) a la unidad utilizando los CLAVOS (1N). escondido 210 grados. NOTA: Asegúrese de clavar ligeramente los CLAVOS dentro de los agujeros que se alinean sobre el PARAL (C) y el ESTANTE (E). www.sauder.com/services 416797 Page 19...
- Page 20 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 20 416797 www.sauder.com/services...
- Page 21 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/services 416797 Page 21...
- Page 22 SIEMPRE descargue los estantes y cajones, empezando con las superfi cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 22 416797 www.sauder.com/services...
- Page 23 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 24 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
