NOMENCLATURE AND FUNCTIONS
4.2 T-4S60-4S120 REAR PANEL
CH 1 OUT
CH 3 OUT
USE ONLY WITHA 250V FUSE
8
8. ~220-240V 50/60Hz POWER INPUT
9. COMMON SPEAKER OUTPUT(CHANNEL 1/2/3/4)
Connectors for 4 ohms or 70V and 100V
speaker
10. AUDIO INPUT
(CH1 IN/CH2 IN/CH3 IN/CH4 IN)
11. FAN
Equipment, exhaust vents, equipment work properly, you must wrap the hole can not have any
object covered, to avoid overheating protection
CH 2 OUT
CH 1 IN CH 2 IN
¦¸ ¦¸ ¦¸ ¦¸
CH 4 OUT
CH 3 IN CH 4 IN
¦¸ ¦¸ ¦¸ ¦¸
9 10
2-HOT+
3-COLD-
1-GND
7
11
