- Page 1 PROFESSIONAL POWER AMPLIFIERS OWNER'S MANUAL OWNER'S MANUAL TS-200PI/TS-350PI/TS-500PI/TS-700PI PRECISION SERIES...
-
Page 2: Table Of Contents
CONTENT DESCRIPTION FEATURES FRONT PANEL BACK PANEL CONNECTIONS SPECIFICATIONS DIMENSIONAL... - Page 3 5. Make sure that the unit is always well ventilated and never exposed to direct sunlight. 6. Do not use sprays to clean the unit as they have a detrimental effect on the unit and Could ignite ITC denly.
-
Page 4: Description
DESCRIPTION DESCRIPTION Thank you very much for choosing an ITC PRECISION SERIES amplifier. We are sure it will give you many years of satisfying performance. ITC power amplifiers of the PRECISION SERIES meet the stringent requirements of tough to- uring applications. They are protected against over-temperature, overload, shorted outputs, radio frequency interference and DC faults. -
Page 5: Features
FEATURES Features: 1. Input sensitivity adjustment. 2. Three operating modes: bridging, stereo and parallel. 3. Enter seat, ground pin ground and suspension control. 4. XLR and 6.35 inputs dual seat. 5. CHA and CHB signal LINK output. 6. With signal indication, protection instructions, instruction limiter, power indicator. 7. -
Page 6: Front Panel
FRONT PANEL Front panel: 1. A channel volume control A potentiometer controls the output volume of amplifier channel A. Clockwising to increase the volume, whereas the volume decreases. 2. Power Switch After the switch is turned on, POWER LED lights after a few seconds. A ?ga?sound can be heard inside relay. -
Page 7: Back Panel
BACK PANEL Back panel: 1.A / B channel balances LINK output. 2. Sensitivity Input switch. There are three positions 1.44V, 1V and 0. 775V (see rear panel diagram). 3. B-channel amplifier output connector. 4. The bridge output connects speaker. 5. AC power input. Connected to the mains supply, please check if the use voltage is consistent with the marked 220V. -
Page 8: Connections
CONNECTIONS POWER AMPLIFIER INPUT CONNECTORS: Connection methods: XLR connector is the connector for balancing transmission signal. The definition of each input pin is: PIN 1: Ground PIN 2: Signal Hot End PIN 3: Signal Cold End INPUT OUTPUT For unbalanced input method, PIN 1 and PIN 3 are short-circuiting. Input sensitivity is 0dB (0.775V). Amplifier output connector: Wiring method is as follows: +1;... - Page 9 CONNECTIONS Connections: Microphone Equalizer Speaker Speaker ( PAGE 6 )
-
Page 10: Specifications
SPECIFICATIONS Model TS-200PI TS-350PI TS-500PI TS-700PI Output Power 200W X 2 350W X 2 500W X 2 700W X 2 Stereo/parallel 8 Stereo/parallel 4 300W X 2 530W X 2 1050W X 2 730W X 2 Bridging 8 600W 1060W 1460W 2100W <-90dB... -
Page 11: Dimensional
DIMENSIONAL K e e p t h e u n i t ’s a l l s i d e s o v e r 1 0 c m a w a y f r o m o b j e c t s t h a t m a y o b s t r u c t a i r f l o w t o p r e v e n t t h e u n i t ’... - Page 12 PROFESSIONAL POWER AMPLIFIERS PRECISION SERIES Version V0.1...
