Figure 13. Performance Data Definitions Screen, Loop Related; Figure 14. Performance Data Definitions Screen, Path Related - ADTRAN T200 H2TU-R Installation And Maintenance Manual

Figure 13 and Figure 14 display the Performance
Data Definitions Screens.
CIRCUIT ID:
H2TUC, H2TUR, and H2R LOOP Related:
ES-L Errored Seconds
SES-L Severely Errored Seconds
UAS-L Unavailable Seconds
DS1 and DSX-1 Line Related:
ES-L Errored Seconds
SES-L Severely Errored Seconds
UAS-L Unavailable Seconds
CV-L Code Violation Count
NOTE: Reverse video indicates invalid data due to a terminal restart (or power
cycle), a data register reset, or a system date or time change.
N. Next
P. Previous

Figure 13. Performance Data Definitions Screen, Loop Related

CIRCUIT ID:
DS1 and DSX-1 Path Related:
ES-P Errored Seconds
SES-P Severely Errored Seconds
UAS-P Unavailable Seconds
CV-P Code Violation Count
NOTE: Under a UAS-P condition, ES-P and SES-P counts are inhibited.
Under a SES-L or SES-P condition, the respective CV-L or CV-P count is
inhibited.
P. Previous

Figure 14. Performance Data Definitions Screen, Path Related

61222024L6-5A
Performance Data Definitions
HDSL2 Framing
CRC>=1 or LOSW>=1
CRC>=50 or LOSW>=1
>10 cont. SES-Ls
Superframe and Extended Superframe
(BPV+EXZ)>=1 or LOS>= 1
(BPV+EXZ)>=1544 or LOS>=1
>10 cont. SES-Ls
(BPV+EXZ) count
Selection:
Performance Data Definitions
Superframe
FE>=1 or
SEF>=1 or AIS>=1
FE>=8 or
SEF>=1 or AIS>=1
>10 cont. SES-Ps
FE count
Selection:
61222024L6-5, Issue 1
01/01/00 03:38:08
01/01/00 03:38:27
Extended Superframe
CRC>=1 or
SEF>=1 or AIS>=1
CRC>=320 or
SEF>=1 or AIS>=1
>10 cont. SES-Ps
CRC error count
11
