Technical Specifications - Omcan FP-CN-0010 Instruction Manual

Technical Specifications

Model
Working Capacity
Electrical
Power
Speed of Motor
Speed of Knife
Speed of Bowl
Diameter of Bowl
Depth of Bowl
Maximum Food Capacity
Minimum Food Capacity
Dimensions
Packaging Dimensions
Weight
Packaging Weight
Item Number
Installation
Make sure there is no damage on the labels outside of carton before unpacking. If there is damage from
transportation (like scars or labels taken off), please list out all the damaged parts in 3 days after the date on
document, and contact with the supplier. While transporting, please keep the machine parallel with the ground,
please do not tip over the machine.
PACKING MATERIAL DISPOSAL
All packing material (cartons, plastic bags, polyurethane foam) can be disposed as normal city garbage. In
countries with special requirements and standard on waste disposal, please dispose according to local laws.
PLACE THE MACHINE
Place the machine in a dry and ventilated level surface, to ensure the smooth and safe machine operation.
Choose a placement space that allows easy access to all parts of the unit.
CONNECTION
Stretching elongation power cord, with grounding symbol of wire core, reliable grounding, three other line core
(single-phase motor for two) respectively received a matching circuit breaker (the user should bring along their
FP-CN-0010
480.6 lbs. / 218 kgs./h
110V / 60Hz / 1
750W
1450r/min
1450r/min
17r/min
18.1" / 460mm
3.3" / 85mm
10 L / 7 kgs.
2.9 L / 2 kgs.
29.9" x 20.3" x 17.8" / 760 x 515 x 452mm
33.6" x 23.7" x 23.7" / 853 x 603 x 601mm
110.2 lbs. / 50 kgs.
144.4 lbs. / 65.5 kgs.
47191
