DESCRIPTION

2. Description
There are different models of as compressed air breathing apparatuses. All
combinations of the below mentioned versions (standard, -S, -Z, CLICK) are
possible.
All combinations can also be equipped with the Integrated Control Unit ICU or
ICU-S (version with key) instead of the pressure gauge.
Retrofitting is possible through MSA or authorized service centres.
1
15
Fig. 1
AirMaXX classic compressed air breathing apparatus (all options)
1 Pressure gauge line
2 Shoulder strap
3 Cylinder separator
4 Cylinder retaining strap
5 Cylinder support
6 Tension clamp
7 Back plate
8 Handle
6
3
2 4
14
AirMaXX classic
5 6
13 12 11
9
10
11
12
13
14
15
7
8
9
10
Catch clip
Push lock
Whistle
Pressure reducer
Medium pressure line
Hip belt
Pressure gauge
