- Page 1 2MP Mini Eyeball 3.6mm Fixed Lens Camera SEE852 © 2021 System Q Ltd ZipDVR.com...
-
Page 2: Table Of Contents
4 NCD / No Image Displayed on Recorder ................. 6 Part 8 General Maintenance Part 9 Specification 1 SEE852 ..........................9 Part 10 Conditions 1 General Company Disclaimer ..................10 2 WEEE Declaration ......................10 3 Copyright ........................10 Index © 2021 System Q Ltd ZipNVR.com... -
Page 3: Part 1 Introduction
Tools & Handy Extras · Screwdriver · Drill · Hammer · 12V DC PSU · Drill bits · BNC Crimp Tool & BNCs · RG59 Coax Cable · Digital Multi-Meter · LCD400K - CCTV Test monitor © 2021 System Q Ltd ZipNVR.com... -
Page 4: Part 3 Connections
This output can be changed with the dip switches on the fly-lead of the camera. Please note the “Output Mode” in the menu of the DVR won’t change the format, as the dip switch overrides the output. The dip switch configuration can be found below:- © 2021 System Q Ltd ZipNVR.com... -
Page 5: Part 5 Mounting
Mounting Mounting 5.1 Mini Eyeball A template is provided in the box for marking the hole positions for the fixing screws. © 2021 System Q Ltd ZipNVR.com... -
Page 6: Part 6 Osd Menu
GLOBAL / CENTRE / BLC / FLC RETURN MODE ATW / MWB / GRAY WORLD RGAIN 1 ~ 127 (Default 40) BGAIN 1 ~ 127 (Default 30) DAY – NIGHT MODE EXT / COLOR / B/W RETURN © 2021 System Q Ltd ZipNVR.com... - Page 7 1080P 25 / 1080P 30 / REBOOT & APPLY RETURN LANGUAGE ENGLISH / SIMPLIFIED CHINESE / TRADITIONAL CHINESE / RUSSIAN / SPANISH / FRENCH / POLISH / ITALIAN / PORTUGUESE RESET SAVE – EXIT EXIT © 2021 System Q Ltd ZipNVR.com...
-
Page 8: Part 7 Troubleshooting
C. Use thicker gauge copper cabling to reduce the voltage drop to the camera, using thicker cable will reduce the resistance between the camera and the power supply and therefore reduce the voltage dropped along the cable. © 2021 System Q Ltd ZipNVR.com... - Page 9 D. Ensure that the BNC – BNC lead that is connected between the camera and DVR has no shorts between the ground and the centre core (positive) or open circuits along the centre core (positive) or open circuits along the ground. © 2021 System Q Ltd ZipNVR.com...
-
Page 10: Part 8 General Maintenance
Routinely check the connections for power and data to ensure no water ingress and corrosion. · Check that the cameras are firmly attached to the wall or mounting bracket. · Check playback in the recorder to ensure the camera is recording and triggering properly. © 2021 System Q Ltd ZipNVR.com... -
Page 11: Part 9 Specification
IR Range Input Voltage 12V DC Current Consumption 300mA (IR On) IP Rating IP66 Video Connection BNC Socket Power Connection 2.1mm DC Socket Finish White/ Grey Build Metal Dimensions 100mm (Diameter) x 90 mm (Height) © 2021 System Q Ltd ZipNVR.com... -
Page 12: Part 10 Conditions
Whilst every effort is made to ensure that these instructions are complete and accurate, System Q Ltd cannot be held responsible in any way for any losses, no matter how they arise, from errors or omissions in these instructions, or the performance or non- performance of the equipment that these instructions refer to. -
Page 13: Index
- D - Rebooting Declaration - S - Dimensions Dip-Switches Screws Disclamer Settings Sharpness - E - Signal Specification Exposure - T - - F - Tools Format Troubleshooting - G - General Disclaimer © 2021 System Q Ltd ZipNVR.com... - Page 14 - V - Video 2, 6 Video Loss Voltage drop - W - WEEE Declaration © 2021 System Q Ltd ZipNVR.com...
