U-Line H-5164 Manual

H-5164
FOLDING PICNIC
TABLE – 6'
TOOLS NEEDED
Power Drill Phillips Head
Leg Assembly x 2
Screw x 8 Bolt x 4
NOTE: Two people are required to assemble this
table. Assemble table on level ground.
1. Lay the tabletop upside down on the ground. Use
the drill to remove the five screws connecting one of
the tabletop channels to the tabletop, and remove
the channel from the table top. (See Figure 1)
NOTE: Do not use a hand screwdriver for this step.
Remove all screws connecting the tabletop
channel to the table top. Save screws for later
use during assembly.
PAGE 1 OF 12
1-800-295-5510
uline.com
3/8" Wrench x 2
Drill Bit
PARTS INCLUDED
Leg Brace Assembly x 2
Locknut x 4 Sliding End Cap x 8
ASSEMBLY
Figure 1
Tabletop Channel
Para Español, vea páginas 5-8.
Pour le français, consulter les pages 9-12.
Tabletop x 1
Bench Seat x 2
Screws
0621 IH-5164
