U-Line H-11436 Installation Instructions

H-11436
FLEXIBLE GUIDE POST
NOTE: It is recommended to install this product
before the ground begins to freeze.
1. Clear away any loose stones or gravel at installation
site prior to digging.
2. Using a post hole digger, shovel or auger, dig a hole
approximately 4" wide and 20" deep.
3. Insert the U-channel end of the post in the hole,
keeping the post as vertical as possible.
NOTE: The reflective face of the post should be
aligned perpendicular to traffic flow.
4. Backfill and tamp the area around the post to
secure it in the ground.
NOTE: For best performance, soil should cover
the entirety of the U-channel post.
(See Figure 1)
5. Repeat for additional post installations.
PAGE 1 of 3
1-800-295-5510
uline.com
INSTALLATION
Pour le français, consulter la page 3.
Figure 1
Ground Level
U-channel must
be below ground
20"
level for proper
performance.
Para Español, vea página 2.
0924 IH-11436
