Abloy PLK/A1 Instructions For Use

PLK/A1
Instructions for use
Certifications
The specs
• Shackle diameter: 10 mm
• Security grading: EN 16864:2017 11440D34
classification
Battery types:
•
For cold environment: Panasonic CR2
For warm environment: Saft LS14250 (use adapter)
CAUTION Risk of explosion if the battery is replaced by
an incorrect type
LED indiations
Color
GREEN
RED
WHITE
BLUE
Function
Wakeup, not connected
Wakeup, connected
Awake, not connected
Awake, connected
Battery poor
Motor drive success (access granted)
Motor drive fail (access granted)
Going to sleep
Changing the battery
1
4
An ASSA ABLOY Group brand
FCC ID: 2AI5J-PLKA1
Basic purpose
Indicates success
Indicates failure
Awake and not connected
Awake and connected
2
3 mm
5
• Battery life: 5 years / 5000 openings
• Operating temperature: -25 +60
• Compatibility: Android devices with BT 4.0 and Android
version 4.4 or newer
• The USB-C port is for service use only. If the battery is
completely discharged, use the USB power bank
(5Vdc 500mA) as backup power.
Color Indication
WHITE Lit for 1 second
BLUE Lit for 1 second
WHITE Blinking with 50ms on 950ms off cycle
BLUE Blinking with 50ms on 950ms off cycle
RED Additional blink for 50ms after awake indication
GREEN Lit for 2 seconds
RED Lit for 2 seconds
WHITE Blinking with 50ms on 150ms off for 1 second
3
x2
2,5 mm
Lock and unlock the
padlock a couple of
times so the firmware
checks the new battery
status.
