Figure 12. 15-Minute Performance History Path Data Screen - ADTRAN DDM+ H2TU-C Installation And Maintenance Manual

The Performance History Screen, illustrated in Figure
12, Figure 13, and Figure 14, displays the historical
HDSL2 and T1 performance data in several different
registers. At each 15-minute interval, the performance
information is transferred to the 15-minute
performance data register. This unit stores
performance data in 15-minute increments for the last
24-hour period. Additionally, some units store up to
CIRCUIT ID:
Menu
1. Definitions
2. Reset Data
3. 15 Min Data
4. 60 Min Data
5. 24 Hr Data
6. Line Data
7. Path Data
8. H2TUC DSX-1
9. H2TUC LOOP
10. H2TUR LOOP
11. H2TUR DS1

Figure 12. 15-Minute Performance History Path Data Screen

12
Press ESC to return to precious menu
15 Minute H2TUC DSX-1 Performance Data
ES-P SES-P UAS-P SAS-P ES-PFE CV-P
000 000
00:00 000 000
23:45 000 000
23:30 000 000
23:15 000 000
23:00 000 000
22:45 000 000
22:30 000 000
22:15 --- ---
22:00 --- ---
21:45 --- ---
21:30 --- ---
21:15 --- ---
Selection:
61222003L1-5, Issue 1
48 hours worth of 60-minute interval data. At each
24-hour interval, the performance data is transferred
into the 24-hour performance data registers. This unit
stores up to 31 days of 24-hour interval data.
The user is prompted to select a module and interface
to view the corresponding performance data. Line (L)
and Path (P) data can be wiewed.
000 000 000
000 000 000
000 000 000
000 000 000
000 000 000
000 000 000
000 000 000
000 000 000
--- --- ---
--- --- ---
--- --- ---
--- --- ---
--- --- ---
_ _ _
--8-->|
| C
<-----|_ _ _|
