Figure 9. Span Status Screen; Figure 10. Detailed Status Screen - ADTRAN DDM+ H2TU-C Installation And Maintenance Manual

The Span Status Screen, illustrated in Figure 9,
provides quick access to status information for each
HDSL2 receiver in the circuit. The legend selection
provides a description of the messages that are used
on the Span Status screens.
CIRCUIT ID:
CIRCUIT ID:
MARGIN(CUR/MIN/MAX): 08/00/10
FRAMING:
LINE CODE:
ES-P/ES-L:
SES-P/SES-L:
UAS-P/UAS-L:
ALARMS:
10
Press ESC to return to precious menu
Span Status Screen
______ <-29dB->
|H2TUC |
<------| |
| |
NET | | <------> |
| |09dB
------>| |
DSX-1 |______|
1. Legend
2. Detailed Status
Selection:

Figure 9. Span Status Screen

Press ESC to return to precious menu
Detailed HDSL2 and T1 Status
HDSL2 RECEIVER DATA
H2TU-C
--------
ATTEN(CUR/MAX): 29/93
ES 15MIN: 010
SES 15MIN: 000
UAS 15MIN: 041
T1 RECEIVER DATA
DSX-1
-------
AUTO
B8ZS
000/001
000/001
000/000
NONE

Figure 10. Detailed Status Screen

61222003L1-5, Issue 1
The Detailed Status selection from the Span Status
Menu, illustrated in Figure 10, displays the HDSL2
and T1 status for each receiver point. From this
screen, all registers can be zeroed, which requires
confirmation and min/max can be reset.
ATTEN
______
|H2TUR |
| |------>
| |
| CUST
10dB| |
MARGIN | |<------
|______| DS1
H2TU-R
--------
11/00/12
29/29
000
000
814
DS1
-------
AUTO
B8ZS
000/008
000/008
822/000
NONE
01/01/00 00:04:23
01/01/00 00:04:53
1. Zero Registers
2. Restart Min/Max
Selection:
61222003L1-5A
