ADTRAN 3192 H4TU-C Brochure

3192 H4TU-C
H TUC
1222404L1
DSL 1
DSL 2
DSX
TX DSX-1 transmit toward the local loop (intrusive)
DSX EQ
/DS1
RX DSX-1 receive from the local loop (intrusive)
ALM
TX
ESF
/SF
TX DSX-1 transmit toward the local loop (nonintrusive)
RX
B8ZS
RX DSX-1 receive from the local loop (nonintrusive)
/AMI
LBK TX
WARNING: Up to –200 VDC might be present on telecommunications wiring. Ensure chassis
RX
DSX MON
This product is intended for installation in restricted access locations only and in equipment
with a Type "B" or "E" enclosure.
ut
R
S
2
3
2
This product provides span powering voltage (negative only with respect to ground, –190 VDC
nominal, GFI protection < 5 mA) and meets all requirements of Bellcore GR-1089-CORE (Class A2),
and ANSI T1.418-2002. This product is NRTL Listed to the applicable UL standards.
The H4TU-C provides –190 VDC span powering voltage and will provide powering to the H4Rs
and the H4TU-R. The –190 VDC span powering voltage is provided on Loop 2.
C A U T I O N ! C A U T I O N
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
Green Loop 1/ Loop 2 synchronization achieved and signal is present.
No errors currently detected, and SNR margin 3 dB.
Red Loop 1/ Loop 2 synchronization not achieved, in sync with errors,
or SNR margin < 3 dB.
Green DSX-1 signal present and no errors currently detected.
Red In framed mode, denotes loss of framing or loss of sync at the
DSX-1 input. In unframed mode, denotes loss of signal DSX-1
input.
Off No T1 alarms are active.
Red Loss of DSX-1 signal from the network.
Yellow Loss of DS1 signal from the CPE.
Off Unit has detected Unframed data.
Yellow Unit has detected ESF framing data.
Green Unit has detected SF framing data.
Yellow Unit has detected B8ZS line coding data.
Green Unit has detected AMI line coding data.
Off No local loopbacks active.
Yellow Local loopback active.
ground is properly connected. The DSX-1 interface is intended for connection to
intra-building wiring only.
3192 H4TU-C
R Tx DSX (In from DSX)
1
R1 Rx DSX (Out to DSX)
2
3
4
GND
5
R1 HDSL4 Loop 2
6
7
—48V
8
R HDSL4 Loop 1
9
Fuse Alarm (to Alarm Module)
10
T Tx DSX (In from DSX)
A
T1 Rx DSX (Out to DSX)
B
C
D
E
T1 HDSL4 Loop 2
F
RCV LOS (to Alarm Module)
H
Frame Ground
J
T HDSL4 Loop 1
K
L
JOB
A
ID
1
