- Page 1 Reliant Light Bar ™ Installation, Maintenance, and Service Manual 25500679 Rev A2 0521 © Copyright 2021 Federal Signal Corporation...
- Page 2 Limited Warranty This product is subject to and covered by a limited warranty, a copy of which can be found at www.fedsig.com/SSG-Warranty. A copy of this limited warranty can also be obtained by written request to Federal Signal Corporation, 2645 Federal Signal Drive, University Park, IL 60484, email to info@fedsig.com or call +1 708-534-3400.
-
Page 3: Table Of Contents
FRONT and REAR lights: CUTOFF (default) or ENABLE ..............11 Making the Electrical Connections for Reprogramming ..............11 Wiring the Reliant Light Bar in the Vehicle ................12 Planning the Electrical Installation ......................12 Connecting Power to the Light Bar ......................13 Low Power .............................. - Page 4 Table 2 Light specifications ........................10 Table 3 Electrical and temperature ......................10 Table 4 SignalMaster warning patterns (internal SM control)) ............15 Table 5 Troubleshooting tips ........................19 Table 6 Replacement parts ........................20 Reliant Light Bar ™ Federal Signal www.fedsig.com...
-
Page 5: Safety Messages
Safety Messages Safety Messages For your safety, read and understand this manual thoroughly before installing, operating, and servicing the Reliant light bar. The safety messages presented in this section ™ and throughout the manual are reminders to exercise extreme care at all times. Read and understand the safety instructions and keep them close at hand for reference. - Page 6 • Before mounting any components, check the manual to verify that the component you are installing is suitable for use in that area of the vehicle. Many components are not suitable for use in the engine compartment or other extreme environmental exposure areas. Reliant Light Bar ™ Federal Signal www.fedsig.com...
- Page 7 Safety Messages • The service life of light bulbs and strobes tubes will be shortened if the glass portion is touched during installation. Use gloves when handling these components. If the glass portion has been touched, clean the glass carefully with isopropyl alcohol.
-
Page 8: Safety Messages To Operators Of Federal Signal Sound/Light Systems
• At the start of your shift, ensure that the entire warning light system and the siren system is securely attached and operating properly. Failure to follow all safety precautions and instructions may result in property damage, serious injury, or death. Reliant Light Bar ™ Federal Signal www.fedsig.com... -
Page 9: An Overview Of The Reliant Light Bar
An Overview of the Reliant Light Bar An Overview of the Reliant Light Bar The Reliant ™ light bar is a single-level LED light bar with ROC (Reliable On-Board Circuitry ™ ) and Solaris LED technologies. ROC eliminates approximately 85 percent of ®... -
Page 10: Reprogramming The Light Bar
If you are missing any parts, contact Customer Support at 1-800-264-3578, 7 am to 5 pm, Monday through Friday (CT). Reprogramming the Light Bar Although the Reliant light bar is configured and programmed at the factory, you may ™ want to change the default settings and flash patterns before installation. Before you begin, decide if you want to change these default settings. -
Page 11: Front And Rear Lights: Cutoff (Default) Or Enable
Reprogramming the Light Bar FRONT and REAR lights: CUTOFF (default) or ENABLE • Set these options after you change the default settings for MODE and INTERSECTION flash patterns. CUTOFF turns OFF the front or rear LEDs when 12 Vdc is applied to the FRONT or REAR light control wire. -
Page 12: Wiring The Reliant Light Bar In The Vehicle
The light bar is completely wired at the factory and does not require any additional internal wiring. All the conductors necessary for control of any and all basic and optional functions are contained in the CAT5 cable. The basic light functions of the Reliant ™ must be controlled by a installer-supplied control head. -
Page 13: Connecting Power To The Light Bar
Wiring the Reliant Light Bar in the Vehicle Figure 2 Cable entry location Front of Light Bar 0.50 Vehicle Cable Entry 5.00 (Under Light Bar) 6. To make wiring easier, remove the seats, spare tire, and pull down the headliner where needed. -
Page 14: Figure 3 Relay For Isolating Devices With Large Filter Capacitors
Wiring the Reliant Light Bar in the Vehicle REVERSE POLARITY / MISWIRING: Reverse polarity or incorrect voltage may damage the light. To avoid damage to the light, ensure that the battery voltage is the same as the voltage rating of the light and that the correct polarity is observed. -
Page 15: Low Power
Wiring the Reliant Light Bar in the Vehicle Low Power NOTE: Low Power Mode and the optional AutoDim feature are disabled when the light bar is in MODE 3 or displaying the Intersection flash pattern. LOW LIGHT HAZARD: Enabling the Low Power function in the light bar may cause the light output to fall below certain current light output standards and guidelines for emergency warning lights. -
Page 16: Maintaining And Servicing The Reliant
Maintaining and Servicing the Reliant Maintaining and Servicing the Reliant This section describes how to maintain and service the Reliant light bar. Establishing a regular maintenance and inspection schedule extends the life of the light bar and ensures safety. For service, support, or replacement parts, contact the Federal Signal Service Department at 1-800-433-9132, 7 am to 5 pm, Monday through Friday (CT). -
Page 17: Replacing A Pcb
Maintaining and Servicing the Reliant 4. To remove fine scratches and haze, use a soft cloth and a high-quality automotive paste cleaner/wax that is non-abrasive. Replacing a PCB The Reliant light bar has two end and two intermediate ROC (Reliable Onboard ™... -
Page 18: Figure 6 Locations Of Roc Pcbs
Maintaining and Servicing the Reliant 7. Loosen the bases from the domes. The lip seal makes it a snug fit. Lift the DS (Driver Side) base and disconnect the harness connected to the PS (Passenger Side). 8. Lift the PS base and disconnect the harness connected to the DS. Remove the bases. -
Page 19: Troubleshooting The Light Bar
• Replace the ROC board that the LED is on. Getting Technical Support and Service For technical support and service, please contact: Service Department Federal Signal Corporation Phone: 1-800-433-9132 Email: empserviceinfo@fedsig.com www.fedsig.com Getting Repair Service The Federal Signal factory provides technical assistance with any problems that cannot be handled locally. -
Page 20: Ordering Replacement Parts
Contact Factory 2645 Federal Signal Drive University Park, Illinois 60484-3167 www.fedsig.com Customer Support Police/Fire-EMS: 800-264-3578 • +1 708 534-3400 Work Truck: 800-824-0254 • +1 708 534-3400 Technical Support 800-433-9132 • +1 708 534-3400 Reliant Light Bar ™ Federal Signal www.fedsig.com...
