The means of the fields below are:
If the field "Name of Station" is checked, the name of the PROFINET slave is defined;
In the field "IP Address" the IP Address of the PROFINET slave is defined;
If the field "Automatic new session when StationProblemIndicator is
PROFINET communication when the error indicator in the slave is present;
In the field "Update Time
In the field "Answer TimeOut" the allowed number of cycles without response from the slave is defined.
Warning:
The data from/to the slaves are mapped consecutively into the IN/OUT PROFINET arrays, following the order with which they are
defined.
