Summary of Contents for Furuno MD-550
- Page 1 MULTI-DISTRIBUTOR MD-550...
- Page 2 9 - 5 2 , A s h i h a r a - c h o , N i s h i n o m i y a , J a p a n T e l e p h o n e : 0 7 9 8 - 6 5 - 2 1 1 1 T e l e f a x : 0 7 9 8 - 6 5 - 4 2 0 0...
- Page 3 Observe the following compass safe distances to prevent deviation of a magnetic compass: Standard compass MD-550 1.40 m Turn off the power switch at the switchboard before beginning the installation. Steering compass 0.95 m...
-
Page 4: Table Of Contents
TABLE OF CONTENTS System Configuration ... 1 Installation materials and Spare parts ... 1 Cables ... 2 Mounting... 2 Setting... 3 Fabrication of signal cable ... 3 SPECIFICATIONS ... SP-1 PACKING LIST OUTLINE DRAWING INTERCONNECTION DIAGRAM SCHEMATIC DIAGRAM... -
Page 5: System Configuration
Output1 Output2 Output3 Output4 Output5 Output6 Output7 Output8 When connecting by current loop, the standard FURUNO receive circuit (current limiter circuit: 470 Output1 photocoupler: PC-400/900 are Output2 included) accepts one unit per output Output3 line. For connection of multiple Output4 equipment, contact a FURUNO agent or dealer for details. -
Page 6: Cables
= 6.6 mm = 3.7 mm Mounting This unit has not power switch. If you do not connect the MD-550 to power switchboard or circuit breaker, install an external power switch (local supply), locating it near the MD-550. Armor Sheath... -
Page 7: Setting
Setting Factory jumper settings are for current loop and “1 in 4 out”. IN1 (OUT1-4) JP1 (#1-#2), Current loop JP2 (#1-#2), JP3 (#1-#2) JP1 (#2-#3), RS-422 JP2 (#2-#3), JP3 (#2-#3) 1 in 4 out #1-#2 1 in 8 out #2-#3 Note1: Put short jumper into connector in same direction as before. -
Page 8: Specifications
Input: IEC 61162-1 or NMEA 0183 Ver. 1.5/2.0 Output: IEC 61162-1 (RS-422) 3. Transmission Rate 4800 bps to 38400 bps 4. Power Supply 12-24 VDC: 0.25-0.15 A 5. Coating Color 2.5G7/2 Newtone No.5 MD-550 (RS-422 or current loop) SP-1 E4408S01B...
