LEGRAND Plexo 0 697 93 Quick Start Manual

PlexoTM - Connected power outlet
0 697 93
This pack is a connected accessory which requires you to buy and install the Plexo with
Netatmo connected starter pack first.
Pack contents
Surface mounting box with membrane
glands (2 gang)
2P+E power outlet
mechanism
Safety instructions
This product should be installed in compliance with installation rules, preferably by a qualified electrician. Incorrect installation and/or incorrect use can
lead to risk of electric shock or fire. Before carrying out the installation, read the instructions and take account of the product' s specific mounting location.
Do not open up, dismantle, alter or modify the device except where specifically required to do so by the instructions. All Legrand products must be
opened and repaired exclusively by personnel trained and approved by Legrand. Any unauthorised opening or repair completely cancels all liabilities
and the rights to replacement and guarantees. Use only Legrand brand accessories.
Necessary safety precautions
Remove the existing
power outlet
OFF
Install the power outlet and the connected power outlet module
Fix the box on the wall
Connected power outlet module
Power outlet module cover
Power outlet cover
Make sure that the power is
off before continuing with the
installation.
3
Before you start: wiring precautions
To control a power outlet, only use the products:
x 1
Connected power outlet
AND AND / OR
x 1
or several
Wireless switch
Do not use: a connected switch (with dimmer option) to control a connected
power outlet or a traditional power outlet.
Install the power outlet and the connected power outlet module (cont.)
Install the membrane glands, the wires and fix the cover plate
The electrical protection must be 16 A
AND / OR
x 1
or several
Wireless switches 1gang or 2 gang
for all control points (not included
in this pack)
2
4
x 1
