Link Power LPS3800-T1 Series
Outdoor Industrial 8-Port Managed
PoE 2-RJ45 & 4-Port SFP Network
Switch
USER MANUAL
Inscape Data Corporation
1620 Oakland Road, STE D101
San Jose, CA 95131
U.S.A.
© Copyright 2015, Inscape Data Corporation, All Rights Reserved. LinkPower, AirEther, AirGoogle,
and Inscape Data are trademarks of Inscape Data Corporation
Disclaimer: While every effort is made to ensure the information given is accurate, Inscape Data
Corporation does not accept liability for any errors or mistakes which may arise. All information and
specifications are subject to change without notice.
Page | 1
Advertisement
Table of Contents
Related Manuals for Inscape Data Link Power LPS3800-T1 Series
Summary of Contents for Inscape Data Link Power LPS3800-T1 Series
- Page 1 Inscape Data are trademarks of Inscape Data Corporation Disclaimer: While every effort is made to ensure the information given is accurate, Inscape Data Corporation does not accept liability for any errors or mistakes which may arise. All information and specifications are subject to change without notice.
- Page 2 Certification Inscape Data Corporation certifies that this product met its published specifications at time of shipment from the factory. FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Inscape Data Corporation assumes no liability for the customer’s failure to comply with these requirements.
-
Page 4: Packing List
WPCK0001-3 AC Power Cord with one 3-PIN AC Power Connector (1) • WPCK0001-4 DC Power Cord with one 4-PIN DC Power Connector (1) – Optional (Please contact Inscape Data via sales@inscapedata.com, if you would like to purchase this part) •... -
Page 5: Table Of Contents
Connector Layout Diagram: ............................11 Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram ............. 12 Optional Accessories ..............................12 Product Dimensions: ..............................13 Wall Mount & Pole Mount : ............................13 Contacting Inscape Data Sales and Support Offices ....................15 Page | 5... -
Page 6: Product Description
Product Description LPS3800-T1 Series Outdoor Industrial PoE Switch features with four PoE Ethernet ports and comply to 10/100/1000BaseT(X), IEEE802.3af/at PoE and two RJ45 and four Gigabit SFP fiber optics uplink interfaces. Each of the PoE ports supplies DC power up to 15.4W for 802.3af and 30W for 802.3at. The transfer data is up to 120Km from SFP fiber port to a control center. -
Page 7: Top Cover
Top Cover To connect the wires, you are simply to open the top cover by the latch. To install and connect the wire, please follow the connector assembly diagram on the next page. Please note the following IP weatherproof rating, when close the top cover: 1. -
Page 8: Ip Management Login
IP Management Login: All network ports of this device support WEB management equipment, IP management by default 192.168.2.1, subnet mask: 255.255.255.0, the default gateway: 192.168.2.254. The administrator of the PC as long as you can communicate with the equipment management. Default IP Address: 192.168.2.1 Default login user: “admin”... -
Page 9: Grounding Protection
Grounding Protection: The system provides the following way to ground the equipment for safety and protection of the system. It is highly recommended that you’re to perform both grounding procedures for maximum safety and protection of your equipment. However, at least of the grounding MUST be performed, otherwise any product damage caused by improper or no grounding will not be covered under warranty. -
Page 10: Power Redundancy & Ups Input
Power Redundancy & UPS Input The switch offers dual power redundancy, i.e., AC & DC input. There are two power inputs, as shown below diagram: When the AC input is connected, the AC is the main power input to the switch. To enable the power redundancy, you connect the DC power to the 4-Pin Terminal with a 48V DC and up to 57V DC power source. -
Page 11: Installation & Mounting
Please click ''Yes'' to restart the switch. 2. Hardware Reset: To perform a hard reset of the system, the Reset Switch is located on the left side of PoE 1 Ethernet Connector, and please hold and press the RESET Switch for 9 seconds. The system will reset automatically. Please be very cautious about the internal wires and cables and DO NOT CHANGE or INTERFERE ANY OF THE INTERNAL WIRES AND CABLES TO PREVENT DAMAGES TO THE SYSTEM. -
Page 12: Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram
Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram Plastic Hole Filler, i.e., Plug Note: The Sealing Insert comes with one and four holes. The Plastic Filler (Plug) MUST be used to cover the Sealing Insert, if any of the hole is not used in order to maintain waterproof of the connector. Optional Accessories The following optional accessories can be order if required: 1. -
Page 13: Product Dimensions
Product Dimensions: Wall Mount & Pole Mount : Support Cable Gland and Conduit Connectors The Hole Size: 1 Inch Diameter Page | 13... - Page 14 ELECTRICAL PIN OUT DIAGRAM Page | 14...
-
Page 15: Contacting Inscape Data Sales And Support Offices
Contacting Inscape Data Sales and Support Offices For more information about Inscape Data Corporation products, applications, support, and for a current sales office listing, visit our web site: http://www.inscapedata.com U.S. Headquarters Here’s how to reach us if you’d like to place an order or if you have questions, concerns, or need support...
