Link Power LPS2802-T1 Series
Outdoor Industrial 8-Port PoE
Network Switch with 2 SFP Uplink
Ports
USER MANUAL
Inscape Data Corporation
1620 Oakland Road, STE D101
San Jose, CA 95131
U.S.A.
© Copyright 2015, Inscape Data Corporation, All Rights Reserved. LinkPower, AirEther, AirGoogle,
and Inscape Data are trademarks of Inscape Data Corporation
Disclaimer: While every effort is made to ensure the information given is accurate, Inscape Data
Corporation does not accept liability for any errors or mistakes which may arise. All information and
specifications are subject to change without notice.
Page | 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Inscape Data Link Power LPS2802-T1 Series
Summary of Contents for Inscape Data Link Power LPS2802-T1 Series
- Page 1 Inscape Data are trademarks of Inscape Data Corporation Disclaimer: While every effort is made to ensure the information given is accurate, Inscape Data Corporation does not accept liability for any errors or mistakes which may arise. All information and specifications are subject to change without notice.
- Page 2 Certification Inscape Data Corporation certifies that this product met its published specifications at time of shipment from the factory. FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Inscape Data Corporation assumes no liability for the customer’s failure to comply with these requirements.
-
Page 4: Packing List
Chassis Power Connection Before connecting or disconnecting ground or power wires to the chassis, ensure that power is removed from the device. To ensure that all power is OFF, locate the circuit breaker on the panel board that services the device, switch the circuit breaker to the OFF position, and tape the switch handle of the circuit breaker in the OFF position. -
Page 5: Table Of Contents
Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram ............11 Installation & Mounting: ............................11 Optional Accessories ............................... 12 Product Dimensions: ..............................12 Wall Mount & Pole Mount : ............................12 Product Specifications ..............................13 Contacting Inscape Data Sales and Support Offices ....................14 Page | 5... -
Page 6: Product Description
Product Description LPS2802-T1 Series Outdoor Industrial PoE Switch features with eight PoE Ethernet ports and comply to 10/100/1000BaseT(X), IEEE802.3af/at PoE and two Gigabit SFP fiber optics uplink interfaces. Each of the PoE ports supplies DC power up to 15.4W for 802.3af, 25.5W for 802.3at, and 30W for 802.3at Plus. The system is integrated with a 200W DC power supply. -
Page 7: Top Cover
Top Cover To connect the wires, you are simply to open the top cover by the latch. To install and connect the wire, please follow the connector assembly diagram on the next page. Please note the following IP weatherproof rating, when close the top cover: 1. -
Page 8: Control Panel Diagram
Control Panel Diagram LED Indicator Description Table: Description Indicator Status Green LED ON Power On, Normal SYS Indicator: POWER LED OFF Power OFF No Connected PD or Power OFF Yellow LED Blink Data transmission properly 1000M Indicator: Link Yellow LED ON Connected with 1000Mbps network device No connected PD Green LED ON... -
Page 9: Grounding Protection
Grounding Protection: The system provides the following way to ground the equipment for safety and protection of the system. It is highly recommended that you’re to perform both grounding procedures for maximum safety and protection of your equipment. However, at least of the grounding MUST be performed, otherwise any product damage caused by improper or no grounding will not be covered under warranty. -
Page 10: Power Redundancy & Ups Input
Power Redundancy & UPS Input The switch offers dual power redundancy, i.e., AC & DC input. There are two power inputs, as shown below diagram: When the AC input is connected, the AC is the main power input to the switch. To enable the power redundancy, you connect the DC power to the 4-Pin Terminal with a 48V DC and up to 57V DC power source. -
Page 11: Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram
Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram Open Cut for Plastic Plug Cable Insert Note: The Sealing Insert comes with one and three holes. The Plastic Plug MUST be used to cover the Sealing Insert, if any of the hole is not used in order to maintain waterproof of the connector. Connector Assembly Diagram Installation &... -
Page 12: Optional Accessories
Optional Accessories The following optional accessories can be order if required: 1. Mast/Pole Mounting Kit (Part No: MMK0001) 2. SFP Duplex 1.25Gbps 3.3V Single-Mode Transceiver (Part No. SFP-SM-LC20-DDM) 3. SFP Duplex 1.25Gbps 3.3V Multimode Transceiver (Part No. SFP-MM-SJ8512-X5PSOS-DDM) Product Dimensions: Wall Mount &... -
Page 13: Product Specifications
Product Specifications ELECTRICAL PIN OUT DIAGRAM Page | 13... -
Page 14: Contacting Inscape Data Sales And Support Offices
Contacting Inscape Data Sales and Support Offices For more information about Inscape Data Corporation products, applications, support, and for a current sales office listing, visit our web site: http://www.inscapedata.com U.S. Headquarters Here’s how to reach us if you’d like to place an order or if you have questions, concerns, or need support...
