Product Description LPS1800 Outdoor Industrial PoE Switch features with four PoE Ethernet ports and comply to 10/100Mbps, IEEE802.3at/af PoE and two Gigabit SFP fiber optics interfaces. The power supply of single PoE port can be up to 15.4W for 802.3af and 25.5W for 802.3at. The transfer data can be up to 120Km from SFP fiber port to a control center.
Control Panel Diagram LED Indicator Description Table: Description Indicator Status Green LED ON Power On, Normal PWR Indicator: SYS LED OFF Power OFF Connected PD Device, working properly Green LED ON Green LED Blink Short circuit or current overload PoE Indicator: PoE No Connected PD or Power OFF No Connected PD or Power OFF Yellow LED Blink Data transmission properly...
Waterproof Ethernet, Fiber Optics, & Power Connector Assembly Diagram Plastic Plug Note: The Sealing Insert comes with one and three holes. The Plastic Plugs MUST be used to cover the Sealing Insert, if any of the hole is not used in order to maintain waterproof of the connector. IP Management Login (Managed Models Only): All network ports of this device support WEB management equipment, IP management by default 192.168.2.1, subnet mask: 255.255.255.0, the default gateway: 192.168.2.254.
6 FT AC Power Cord: White (W) – AC/L • Green (G) – Ground • Black (B) – AC/N • AC Power Cable: DC Power Cable (Optional): White (W) – AC/N If Available Green (G) – Ground 1. White (W) – Positive 3.
Power Supply) is highly recommended. A 48V DC UPS can be either an AC to DC UPS or solar-powered DC backup UPS. Once the DC power is connected, the DC power functions as backup power. If the AC is not used and the DC power is connected, then the DC power functions as the main power.
Installation & Mounting: You can mount the system with one of the two ways: 1. Wall Mount 2. Pole Mount Wall Mount Kit, Standard Accessory (Optional Accessory, MMK001 Pole Mount Kit) Page | 11...
