SINGLE OVEN DUAL FUEL RANGE
VDFSGE365..
Models:
INSTALLATION INSTRUCTIONS
IMPORTANT - PLEASE READ AND FOLLOW
•
Before beginning, please read these instructions completely and carefully.
•
Do not remove permanently affixed labels, warnings, or plates from the product. This may
void the warranty.
•
Please observe all local and national codes and ordinances.
•
Please ensure that this product is properly grounded.
The installer should leave these instructions with the consumer who should retain
•
for local inspector's use and for future reference.
IN CANADA: The electrical plug should always be accessible.
•
Installation must conform with local codes or in the absence of codes, the National Fuel Gas
Code ANSI Z223.1/NFPA 54 - Iatest edition. Electrical installation must be in accordance
with the National Electrical Code, ANSI/NFPA70 - latest edition and/or local codes. IN
CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
INSTALLATION IN MANUFACTURED (MOBILE) HOME: The installation must conform
with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280
[formerly the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD
(Part 280)] or, when such standard is not applicable, the Standard for Manufactured Home
Installations, ANSI/NCSBCS A225.1, or with local codes where applicable.
INSTALLATION IN RECREATIONAL PARK TRAILERS: The installation must conform with
state or other codes or, in the absence of such codes, with the Standard for Recreational
Park Trailers, ANSI A119.5.
Installation of any gas-fired equipment should be made by a Iicensed plumber. A manual
shut-off valve must be installed in an accessible location in the gas line external to the
appliance for the purpose of turning on or shutting off gas to the appliance (In Massachusetts
such shutoff devices should be approved by the Board of State Examiners of Plumbers &
Gas Fitters).
If an external electrical source is utilized, the appliance, when installed, must be electrically
grounded in accordance with local codes or, in the absence of local codes, with the national
Electrical Code, ANSI/NFPA 70.
Some models are supplied with a protective film on steel and aluminium
parts. This film must be removed before installing/using the appliance.
THIS RANGE IS FOR RESIDENTIAL USE ONLY
FOR INSTALLER ONLY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Verona VDFSGE365 Series
Summary of Contents for Verona VDFSGE365 Series
- Page 1 SINGLE OVEN DUAL FUEL RANGE VDFSGE365.. Models: INSTALLATION INSTRUCTIONS IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty.
-
Page 2: What To Do If You Smell Gas
WARNING Tip-Over Hazard A child or adult can tip the range and be killed. Install anti-tip device to range and/or structure per installation instructions. Engage the range to the anti-tip device Installed to the structure. Re-engage anti-tip device if range is moved. Failure to follow these instructions can result in death or serious burns to children and adults. -
Page 3: Data Plate
DATA PLATE The product data plate is attached below the bottom drawer. To check the label, it is necessary to remove the drawer (see “Setting pressure regulator” for instructions on drawer removal). CONVERSION LABEL WARNING: This product can expose you to chemicals including formaldehyde, which is known to the State of California to cause cancer, and lead, which is known to the State of California to cause birth defects or other reproductive harm. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. Installation must conform with local codes. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a qualified installer, service agente or the gas supplier. IMPORTANT: The use of suitable protective clothing/gloves is recommended when handling or installing this appliance. -
Page 5: General Information
GENERAL INFORMATION 16. When installing or removing the range for service, a rolling lift jack should be used. Do not push against any of the edges of Installation must conform with local codes or, in the absence the range in an attempt to slide it into or out of the installation. of local codes, with the National Fuel Gas Code, ANSI Pushing or pulling a range (rather than using a lift jack) also increases the possibility of bending the leg spindles or the... - Page 6 installation PROXIMITY TO SIDE CABINETS hood” here below) above the cooking surface, for a width of minimum 36” (914 mm): it has to be centered with the range. This range may be installed directly adjacent to existing 36” Side wall cabinets above the range must be a minimum of (914 mm) high base cabinets.
- Page 7 GAS AND ELECTRIC CONNECTION Ref. inch Dotted line showing the position of the range when installed 1/4” 23” 9/16 8” 1/8 - 10” 1/8 (*) 207 - 257 (*) 11” 13/16 (*) : Depending on feet regulation Area for ELECTRICAL connection Area for GAS connection...
- Page 8 PROXIMITY TO SIDE CABINETS Ref. inch 0” 37” 1/2 (*) 953 (*) Fig. 1.4a 11” 13/16 30” or 36” minimum (**) 762 or 914 minimum (**) 18” minimum 457 minimum 13” maximum 330 maximum 20” minimum 500 minimum 0” Maximum height of cabinetry immediately adjacent to the range (from floor to countertop).
-
Page 9: Fitting The Adjustable Feet
Fig. 1.6 Fig. 1.5 FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for the fitting of the feet. ATTENTION: Most important! Pay special attention not to damage the range during this operation. -
Page 10: Installing The Anti-Tip Bracket
INSTALLING THE ANTI-TIP BRACKET The anti-tip bracket has two components: • the adjustable bracket • the stability bracket IMPORTANT! You must install both parts of the anti-tip bracket and ensure they are properly fitted together to prevent the range from tipping. To fit the anti-tip bracket Fig. - Page 11 Fix the stability bracket in place. It can WARNING be fixed as follows: Tip-Over Hazard To the floor OR on the rear wall by #4 • A child or adult can tip the range and be killed. screws (supplied). To the floor AND on the rear wall by #8 •...
- Page 12 INSTALLING THE COOKTOP FRONT GUARD (Only for the models without hob rail) To increase the clearance between the front edge of the cooktop and the burners it is possible to install the cooktop front guard supplied with the appliance. IMPORTANT: To install/remove the guard it is necessary to remove the cooktop. Attempting to install/remove the guard without disassembling the cooktop will result in permanent damage to the appliance.
- Page 13 gas connection All gas connections must be made according to national and local codes. This gas supply (service) line must be the same size or greater than the inlet line of the appliance. Sealant on all pipe joints must be resistant to the action of LP/Propane gas. The range is equipped for the use with NATURAL gas.
- Page 14 PRESSURE REGULATOR INSTALLATION STEP 1 Regulator cover Mount the 1/2” NPT (conical) male connector to the pressure regulator and tighten by using a wrench. Do not over tighten the connector. Over tightening may crack regulator. Lock Arrow Fig. 2.2 STEP 2 Assemble the 1/2”...
- Page 15 STEP 3 Assemble the extension pipe + pressure regulator group to the range manifold interposing the gasket supplied. The regulator cover must be ordiented toward the front side of the range. IMPORTANT: use two spanners to tighten the connection. Gasket Fig.
- Page 16 GAS CONNECTION SPECIFICATION Range To range manifold Manifold male pipe tting 1/2” G cylindrical (ISO 228-1) male Gasket 1/2” G cylindrical (ISO 228-1) female Extension pipe female pipe tting f i t To mains connection Extension pipe Extension Pressure Gasket pipe male regulator pipe tting...
- Page 17 Any conversion required must be performed by your dealer or a qualified licensed technician or gas service company. Please provide the service person TEST POINT ADAPTER with this manual before work is started on the range. (Gas conversions are the The Test Point adapter is available from the responsibility of the dealer or end user.) After-Sales Service.
-
Page 18: Setting The Pressure Regulator
CONVERSION TO LP/PROPANE GAS (OR CONVERSION BACK TO THE ORIGINAL GAS - NATURAL GAS) Every range is provided with a set of injectors for the various types of gas. Select the injectors to be replaced according to the “INJECTORS TABLE”. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector. - Page 19 To set the pressure regulator (fig. 2.9) Pressure regulator Unscrew the regulator cover. Unscrew the “A” component, reverse and screw it according to the LP/PROPANE (or NATURAL GAS) regulation. REGULATOR COVER NATURAL GAS LP/PROPANE REGULATION REGULATION Fig. 2.9 Refit the storage drawer: Insert the drawer guides into the range guides (fig.
-
Page 20: Injectors Table
INJECTORS TABLE LP/PROPANE NOMINAL REDUCED NATURAL GAS POWER POWER 11” W.C.P. 4” W.C.P. Ø injector Ø injector BURNERS BTU/hr BTU/hr [1/100 mm] [1/100 mm] Semirapid (SR) 8000 1500 Triple-ring (TR) 12000 5000 2800 ( 1 ) 1100 ( 1 ) 50 ( 3 ) 80 ( 3 ) Inner crown... - Page 21 SETTING THE BURNER MINIMUM When switching from one type of gas to another, the minimum flow rate must also be correct: the flame should not go out even when passing suddenly from maximum to minimum flame. To regulate the flame (fig. 2.14) follow the instructions below: Triple-ring and semirapid burner •...
-
Page 22: Electrical Requirements
electrical connection ELECTRICAL REQUIREMENTS • This appliance must be properly installed and grounded by a qualified technician in WARNING accordance with the National Electrical Code ANSI/NFPA No.70 (latest edition) and local electrical code requirements. IN CANADA: Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical Codes Part1 and/or local TO AVOID ELECTRICAL SHOCK codes. - Page 23 PERMANENT CONNECTION (HARD WIRING) US only, for Canada it is mandatory to connect the range by Terminal Block using cordset with plug supplied. • Units may be hard wired to the power supply. The installer must provide approved flexible aluminium conduit, 3/4” (19mm) trade size, maximum 6ft (1.8m) long.
- Page 24 RANGES SUPPLIED WITH POWER CORD (WITH PLUG) ALREADY FITTED If codes permit and a separate ground wire is used, it is recommended that a qualified electrician installer determine that the ground path and wire gauge are in accordance with local codes. Be sure that the electrical connection and wire size are adequate and in conformance with: •...
-
Page 25: Wiring Diagram
WIRING DIAGRAM... - Page 28 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances.
