INDUCTION RANGE
for residential use only
VDFSIE365..
Models:
INSTALLATION INSTRUCTIONS
IMPORTANT - PLEASE READ AND FOLLOW
•
Before beginning, please read these instructions completely and carefully.
Do not remove permanently affixed labels, warnings, or plates from the product. This may
•
void the warranty.
•
Please observe all local and national codes and ordinances.
•
Please ensure that this product is properly grounded.
•
The installer should leave these instructions with the consumer who should retain
for local inspector's use and for future reference.
IN CANADA: The electrical plug should always be accessible.
•
Electrical installation must be in accordance with the National Electrical Code, ANSI/NFPA70
- latest edition and/or local codes.
IN CANADA: Electrical installation must be in accordance with the current CSA C22.1
Canadian Electrical Codes Part 1 and/or local codes.
Some models are supplied with a protective film on steel and aluminium
parts. This film must be removed before installing/using the appliance.
THIS RANGE IS FOR RESIDENTIAL USE ONLY
FOR INSTALLER ONLY
R
Advertisement
Table of Contents
Related Manuals for Verona VDFSIE365SG
Summary of Contents for Verona VDFSIE365SG
- Page 1 INDUCTION RANGE for residential use only VDFSIE365.. Models: INSTALLATION INSTRUCTIONS IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. Do not remove permanently affixed labels, warnings, or plates from the product. This may •...
- Page 3 WARNING Tip-Over Hazard A child or adult can tip the range and be killed. Install anti-tip device to range and/or structure per installation instructions. Engage the range to the anti-tip device Installed to the structure. Re-engage anti-tip device if range is moved. Failure to follow these instructions can result in death or serious burns to children and adults.
-
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. Installation must conform with local codes. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a qualified installer or a service agent. IMPORTANT: The use of suitable protective clothing/gloves is recommended when handling or installing this appliance. -
Page 5: General Information
GENERAL INFORMATION WARNING!! WARNING!! ELECTRICAL GROUNDING INSTRUCTIONS This appliance shall not be used for space heating. This The range must be electrically grounded in accordance with information is based on safety considerations. local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA No. - Page 6 installation PROXIMITY TO SIDE CABINETS The maximum upper cabinet depth recommended is 13” (330 This range may be installed directly adjacent to existing 36” mm). A ventilation hood or a wall cabinet above the range (914 mm) high base cabinets. must be a minimum of 24"...
-
Page 7: Electric Connection
ELECTRIC CONNECTION Ref. inch Dotted line showing the position 7/32” of the range when installed 35” 7/16 8” 1/8 - 10” 3/32 (*) 206.5 - 256.5 (*) (*) : Depending on feet regulation Area for ELECTRICAL connection Fig. 1.2 ISLAND TRIM ISLAND TRIM AND BACKGUARD •... - Page 8 PROXIMITY TO SIDE CABINETS STANDARD INSTALLATION AND ISLAND INSTALLATION Ref. inch Fig. 1.4a 0” 36” (*) 914 (*) 2” 24" or 30” minimum (**) 610 or 762 minimum (**) 18” minimum 457 minimum 13” maximum 330 maximum 20” minimum 500 minimum 0”...
-
Page 9: Fitting The Adjustable Feet
Fig. 1.5 Fig. 1.6 FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for the fitting of the feet. ATTENTION: Most important! Pay special attention not to damage the range during this operation. -
Page 10: Installing The Anti-Tip Bracket
INSTALLING THE ANTI-TIP BRACKET The anti-tip bracket has two components: the adjustable bracket • the stability bracket • IMPORTANT! You must install both parts of the anti-tip bracket and ensure they are properly fitted together to prevent the range from tipping. To fit the anti-tip bracket Fig. - Page 11 Fix the stability bracket in place. It can be WARNING fixed as follows: Tip-Over Hazard To the floor OR on the rear wall by #4 • screws (supplied). A child or adult can tip the range and be killed. To the floor AND on the rear wall by #8 •...
- Page 12 electrical connection ELECTRICAL REQUIREMENTS • This appliance must be properly installed and grounded by a qualified technician in WARNING accordance with the National Electrical Code ANSI/NFPA No.70 (latest edition) and local electrical code requirements. IN CANADA: Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical Codes Part1 and/or local TO AVOID ELECTRICAL SHOCK codes.
- Page 13 PERMANENT CONNECTION (HARD WIRING) US only, for Canada it is mandatory to connect the range by Terminal Block using cordset with plug supplied. Units may be hard wired to the power supply. The installer • must provide approved flexible aluminium conduit, 3/4” (19mm) trade size, maximum 6ft (1.8m) long.
-
Page 14: Only For Canada
RANGES SUPPLIED WITH POWER CORD (WITH PLUG) ALREADY FITTED If codes permit and a separate ground wire is used, it is recommended that a qualified electrician installer determine that the ground path and wire gauge are in accordance with local codes. Be sure that the electrical connection and wire size are adequate and in conformance with: ANSI/NFPA 70 latest edition and local codes and ordinances;... -
Page 15: Wiring Diagram
WIRING DIAGRAM... - Page 16 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances.
