UD-064 600W x 4 High Efficient Switching Power Amplifier
Contents:
Overview & Features
In & Out Interface
The latest version of this manual with color illustration is available for download from our product pages below,
www.unika.com.tw/products-view.php?ID=166
tw.unika.com.tw/products-view.php?ID=167
UD-064D with Dante Input
(English)
(中文手冊)
UNiKA Electronic Co., Ltd.
www.unika.com
6F, No.168, XinHu 2nd Road,
NeiHu Dist., Taipei 11494,
Taiwan (R.O.C.)
☏ +886-2-27933017
✉ unika@unika.com.tw
08/23/2021
Advertisement
Related Manuals for Unika UD Series
Summary of Contents for Unika UD Series
-
Page 1: Table Of Contents
UD-064 600W x 4 High Efficient Switching Power Amplifier UD-064D with Dante Input Contents: Overview & Features Description Getting Started Configurations UNiKA Electronic Co., Ltd. eXtraTone & LPF www.unika.com In & Out Interface 6F, No.168, XinHu 2nd Road, Dante NeiHu Dist., Taipei 11494, Applications Taiwan (R.O.C.) - Page 2 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Overview: The UD-064/UD-064D is a high efficient switching power amplifier with a concise and intuitive digital control interface. The amplifier is designed to achieve its maximum output by paralleling speakers on its outputs.
-
Page 3: Description
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Description: The UD-064/UD-064D is a high efficient switching power amplifier with a concise and intuitive digital control interface and elegant style of aluminum facet. Although it comes in capability of high power driving, the amplifier is crammed into 1U in height and merely sub ten kilogram in weigh due to its adoption of power efficient and advanced switching technologies in both power supply and power amplification. - Page 4 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty as input parallelization, out bridging, input selecting, input sensitivity selecting, and etc., are set in a digital way to minimize the chance of hardware failure.
-
Page 5: Getting Started
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Getting Started Guide: Installation Although the internal processor of UD-064/UD-064D can optimize the performance of the amplifier according to the operating environment, too much high operation temperature and intermittent AC source void the guarantee of the operation of the amplifier to meet the specifications. - Page 6 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty want, and briefly press the ENCODER again to complete the editing and exit edit mode. Pressing the BACK button when the ENCODER is in edit mode can also bring back the ENCODER to browse mode.
- Page 7 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty to other menus by briefly pressing the INFO/SET button or go to SETTINGS menu by long pressing the INFO/SET button.
- Page 8 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty UID: Unique ID assigned to the device SW: Firmware Version in the device ACin: AC Voltage (roughly estimated)
- Page 9 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty TEMP menu: A thermometer icon is stayed on the upper left of the display when the content of TEMP menu is being browsed.
-
Page 10: Configurations
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Device Configurations: Long pressing the INFO/SET button more than one second will bring up the SETTINGS menu. You can browse the content SETTINGS menu by rotating the ENCODER. - Page 11 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Similarly, BTL3&4 and PAR3&4 are also exclusive to each other which means enabling BTL3&4 automatically disabling PAR3&4, and vice versa.
- Page 12 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Auto-Save and Reset Device Settings/Configurations Auto-Save: All the items of settings or configurations, including the items for volume and eXtraTone™, you change in edit mode are saved automatically when you press the BACK button to leave the browse mode.
- Page 13 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Error & Service Message Although it is scarcely, you may see some kind of messages with a wrench icon on the upper left of the display. This is...
- Page 14 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Dante interface. Dante in Upgrading: Dante interface is in a process of software upgrading. Please wait for the upgrade to complete and then re-power the amplifier.
-
Page 15: Extratone & Lpf
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty eXtraTone™ to Boost the Bass Performance of Speakers eXtraTone™ is an unprecedented digital algorithm to boost and compensate speaker for loss below its bass cutoff. - Page 16 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty LPF Filter and LPFMix Function for Subwoofer Subwoofer is always power hungry, therefore, you may have to, 1. reserve more power for subwoofer by connecting subwoofer to a bridged output, or 2.
- Page 17 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty built-in LPFMix function in UD-064/UD-064D to automatically generate a mono mixed from the other channels and have the mono mix to feed to the input of LFP filter. Please look into the above block diagram for understanding how LPFMix is positioned in the signal path.
- Page 18 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Analog Audio Inputs By default, the UD-064/UD-064D is configured to receive audio from analog inputs via balanced XLR sockets on the rear panel. The...
-
Page 19: Dante
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Dante Audio Network Interface for UD-064D: The UD-064D adopts Audinate Dante networking technology for AoIP (Audio over IP) receiving. - Page 20 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty There are two LEDs on each of the RJ-45 ports for the Dante interface. The LEDs reveal the network status described as follows,...
-
Page 21: Applications
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Applications: Dante Networking without Switch One of the beauties of Dante is that you do not need a DHCP server or router in between to establish all kinds of communication among different Dante-enabled devices. - Page 22 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Power Output to Speaker There are lots of variety of output configurations that can be achieved through the high drive capability and high connection flexibility of output of the UD-064/UD-064D amplifier.
- Page 23 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Output to Line Array The UD-064/UD-064D is initially designed to seamlessly work with line arrays. Audio technicians can...
- Page 24 UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty...
-
Page 25: Specifications
UNiKA UD-064 & UD-064D Switching Power Amplifier Overview Description Getting Started Configurations eXtraTone & LPF In & Out Dante Applications Specifications Warranty Specifications: Model UD-064 UD-064D AC110V 2.3KW AC120V 2.8KW Total Output AC127V 3.3KW AC220V 3.3KW AC240V AC110V 240W@8Ω 400W@4Ω 600W@2Ω... -
Page 26: Warranty
UNiKA products are designed and manufactured in Taiwan to the highest quality standard. However, if something does go wrong with a product, UNiKA Electronic Co., Ltd. will repair or replace such product in accordance with this warranty policy in any country served by an authorized UNiKA distributor. This warranty complements any national or regional law obligations of dealers, partner or national distributors and does not affect your statutory rights as a consumer.
