Technical Specifications

Type Name
Supply
Voltage
Current
Power Supply
Parameters
Three Phases and Neutral of a 3P4W system
Direct Voltage Input : Up to 300V L-N
Burden
Secondary Current: 5A or 1A ( optional )
Input
CT Primary : Site Selectable
Range of Reading : 5 -5000A
Burden : < 1.0VA
Overload : 5A CT = 6A RMS Continuous
(Through CT) 1A CT = 1.2A RMS Continuous
(Whole Current) : 120% of Imax continuous.
Wide operating Voltage SMPS : 80VAC -
300VAC, 50-60 H
4
Statistics
: 0.5VA
