Infinity – Operational Manual
Type
RS485 Port
Total Active
Energy (KWh)
Total Apparent
Energy (KVAh)
Bezel
Panel Cutout
Depth of
installation
Operating temp
Weight
Min. Operating
Current
Dual Source
Sensing
Run Hour and Load Run Hour (Any One Parameter Available Through Programming Mode)
Name
Supporting MODBUS-RTU protocol.
Range of Reading
Accuracy
Range of Reading : 0 to 9999999.9 KVAh
Accuracy : 1.0S as per IS13779.
(Energy Measurement Selection In Programming Mode)
96 X 96 mm
92 X 92 mm
55 mm
10 C to 50 C
0.276 Kgs
0.4% of CT primary.
By presence or absence of 230VAC across
two terminals. Can be looped.
Parameters
Statistics
O O
5
: 0 to 9999999.9 KWh
: 1.0S as per IS13779.
