Racing Steering Wheel Stand
Instruction Manual
SKU: STAND-RACE1A
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-race1a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-RACE1A
Summary of Contents for Vivo STAND-RACE1A
- Page 1 Racing Steering Wheel Stand Instruction Manual SKU: STAND-RACE1A Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-race1a GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. - Page 3 STEP 2 Loosen the knobs on the middle of the post on Stand (A), then extend the post. Remove the two knobs locking the post in the folded position. Raise the post, then install the Upright Support Plate (B) to the base and post using M8x16 Screws (F) and the previously removed knobs.
- Page 4 STEP 4 Remove the knobs from the foot plate in Stand (A). Remove the screws using 5mm Allen wrench (H), move the foot plate to the desired position (1-5), then reinstall the screws. STEP 5 Adjust the foot plate on Stand (A) to the desired angle and reinsert the previously removed knobs.
- Page 5 STEP 6 Adjust the post on Stand (A) to the desired height, then tighten the knobs to secure the height. STEP 7 Install Shifter Support Bracket (I) to the left or right side of the wheel support plate on Stand (A) using M6x12 Screws (K).
- Page 6 STEP 8 Mount Shifter Plate (J) to Shifter Support Bracket (I) using M6x12 Screws (K) and tighten with 5mm Allen wrench (H). Shifter Plate (J) may be installed to the close or far position depending on user preference. STEP 9 Attach Cable Clips (E) to the post on Stand (A) for cable management.
- Page 7 STEP 10 FOLDING INSTRUCTIONS Remove the lower two knobs (A1) from the UprightSupport Plate (B) and gently fold the post down. Loosen the knobs on the middle of the post to extend for clearance if needed. Reinsert the previously removed knobs into the sides to lock the post in the folded position.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
