Atlantic Furniture URBAN LIFESTYLE BED DRAWER Assembly Instructions

please contact Atlantic Furniture at service@atlanticfurniture.com or 1-800-955-3726
Allen wrench
NOTE : WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
A
JCB M6 X 1 1/8"( 30mm ) - 16 pcs
PARTS LIST
01
HARDWARE
02
DRAWER FACE
03
DRAWER SIDE
04
DRAWER BACK
05
DRAWER BOTTOM
Step 1
Lay the drawer face (02) on smooth, flat surface so the groove is facing upwards. Fit the drawer
side (03) to drawer face (02), Use JCB M6 X 1" (A), align groove inside panel with groove in
drawer face. Tighten with Allen wrench (B).
A
PO :
URBAN LIFESTYLE BED DRAWER
ASSEMBLY INSTRUCTIONS
Before assembling your bed drawer, please read through these
instructions carefully, familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
Spare - 2 pcs
1 BOX
2 PCS
4 PCS
2 PCS
2 PCS
03
02
HARDWARE
03
02
B
Allen wrench - 1 pc
Spare - 1 pc
E
04
05
03
03
A
READY
Adult assembly
01
Adult assembly
A
JCB M6 X 1 1/8"
B
Allen wrench
Page 1 of 2
