The length and width of the upper bunk mattress and foundation are as follows :
Length
74"- 75"
Ensure thickness of mattress and foundation combined does not exceed 9 ½"
and that the mattress is at least 5" below upper edge of guardrails.
Replacement parts, including additional guardrails, may be obtained from any
!
Follow the information on the warnings appearing on the upper bunk end structure
( 1 )
and on the carton. Do not remove warning label from bed.
( 2 )
Always use the recommended size mattress or mattress support, or both,
to help prevent the likehood of entrapment or falls.
( 3 )
Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
( 4 )
Do not allow children under 6 years of age to use the upper bunk.
( 5 )
Periodically check and ensure that the guardrail, ladder, and other component are
in their proper position, free from damage, and that all connectors are tight.
( 6 )
Do not allow horseplay on or under the bed, and prohibit jumping on the bed.
( 7 )
Always use ladder for entering or leaving upper bunk.
( 8 )
Do not use substitute parts. Contact the manufacturer for replacement parts.
( 9 )
Use of a night light may provide added safety precaution for a child using the upper bunk.
(10)
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to a wall, the guardrail that runs the full length of the bed must be placed
against the wall to prevent entrapment between the bed and the wall.
(11)
The use of water or sleep flotation mattress is prohibited.
(12)
Prohibit more than one person on upper bunk.
(13)
STRANGULATION HAZARD : Never attach or hang items to any part of the Bunk Bed
that are not designed for use with the bed: for example, but not limited to, hooks, belts
and jump ropes.
(14)
Keep these instructions for future reference.
BUNK SAFETY WARNING
Size of Mattress and Foundation
37 ½"- 38 ½"
You must use only this size mattress.
This Bunk Bed uses a slat kit for mattress foundation.
Replacement Parts
Atlantic Furniture dealer
SAFETY WARNINGS
Width
TT 09282009
Thickness
9 ½" max
!
