READY
URBAN LIFESTYLE TRUNDLE BED
instructions carefully, familiarize yourself with the different parts.
BED WITH FLAT PANEL TRUNDLE BED
NOTE : WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB OR BARREL NUT ARE DAMAGED DURING ASSEMBLY.
A
JCB M6 X 2 3/8 "( 60mm ) - 4 pcs
B
JCB M6 X 1 ½"( 40mm ) - 17 pcs
C
JCB M6 X 5/8"( 15mm ) - 6 pcs
Fix L Bracket to Front Panel
URBAN LIFESTYLE TRUNDLE BED
ASSEMBLY INSTRUCTIONS
Before assembling your trundle bed, please read through these
HARDWARE
Spare - 1 pc
Spare - 2 pcs
Spare - 2 pcs
E
D
Barrel Nut - 4 pcs
Spare - 1 pc
For JCB M6 X 2"(50mm )
E
L Bracket - 3 pcs
F
Allen wrench - 1 pc
Spare - 1 pc
Adult Assembly
Allen wrench
Page 1 of 4
Advertisement
Related Manuals for Atlantic Furniture Urban Lifestyle Trundle Bed
Summary of Contents for Atlantic Furniture Urban Lifestyle Trundle Bed
- Page 1 READY URBAN LIFESTYLE TRUNDLE BED ASSEMBLY INSTRUCTIONS Before assembling your trundle bed, please read through these instructions carefully, familiarize yourself with the different parts. Adult Assembly BED WITH FLAT PANEL TRUNDLE BED Allen wrench HARDWARE NOTE : WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB OR BARREL NUT ARE DAMAGED DURING ASSEMBLY.
-
Page 2: Parts List
Attach the side cross rail (05) center cross rail (06) to the front and back rail (03)(04), using L bracket (E), JCB M6 X 1 1/2”(B). Tighten with the Allen wrench (F). Page 2 of 4 URBAN LIFESTYLE TRUNDLE BED... - Page 3 Adult Assembly JCB M6 X 1 1/2” Allen wrench Lay the slat kit (08) onto the rail assemblies as shown, using JCB M6 X 1 1/2” (B). Tighten with the Allen wrench (F). Page 3 of 4 URBAN LIFESTYLE TRUNDLE BED...
- Page 4 Your Trundle Bed is now ready for use. We recommend that you recheck that all screws are tight, and that all parts are secure before use and periodically to ensure lasting Safety. Page 4 of 4 URBAN LIFESTYLE TRUNDLE BED...
