The length and width of the upper bunk mattress and foundation are as follows :
Length
74"- 75"
Ensure thickness of mattress and foundation combined does not exceed 9 ½"
and that the mattress is at least 5" below upper edge of guardrails.
Replacement parts, including additional guardrails, may be obtained from any
!
Follow the information on the warnings appearing on the upper bunk end structure
( 1 )
and on the carton. Do not remove warning label from bed.
( 2 )
Always use the recommended size mattress or mattress support, or both,
to help prevent the likehood of entrapment or falls.
( 3 )
Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
( 4 )
Do not allow children under 6 years of age to use the upper bunk.
( 5 )
Periodically check and ensure that the guardrail, ladder, and other component are
in their proper position, free from damage, and that all connectors are tight.
( 6 )
Do not allow horseplay on or under the bed, and prohibit jumping on the bed.
( 7 )
Always use ladder for entering or leaving upper bunk.
( 8 )
Do not use substitute parts. Contact the manufacturer for replacement parts.
( 9 )
Use of a night light may provide added safety precaution for a child using the upper bunk.
(10)
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to a wall, the guardrail that runs the full length of the bed must be placed
against the wall to prevent entrapment between the bed and the wall.
(11)
The use of water or sleep flotation mattress is prohibited.
(12)
Prohibit more than one person on upper bunk.
(13)
STRANGULATION HAZARD : Never attach or hang items to any part of the Bunk Bed
that are not designed for use with the bed: for example, but not limited to, hooks, belts
and jump ropes.
(14)
Keep these instructions for future reference.
BUNK SAVETY WARNING
Size of Mattress and Foundation
37 ½"- 38 ½"
You must use only this size mattress.
This Bunk Bed uses a slat kit for mattress foundation.
Replacement Parts
Atlantic Furniture dealer
SAFETY WARNINGS
Width
09292009
Thickness
9 ½" max
!
Page 1 of 7
Advertisement
Related Manuals for Atlantic Furniture WINDSOR BUNK BED
Summary of Contents for Atlantic Furniture WINDSOR BUNK BED
- Page 1 This Bunk Bed uses a slat kit for mattress foundation. Replacement Parts Replacement parts, including additional guardrails, may be obtained from any Atlantic Furniture dealer SAFETY WARNINGS Follow the information on the warnings appearing on the upper bunk end structure ( 1 ) and on the carton.
- Page 2 Thank you for choosing our new bunk bed. This practical design offers the utmost in versatility. Before assembling your Windsor bunk bed, please read through these instructions carefully, familiarising yourself with the different parts. Please note that you will require a Phillips head screwdriver and an Allen wrench (provided).
-
Page 3: Parts List
BOX 1 of 4 LOWER PANEL BOX 2 of 4 FULL GUARDRAIL 3/4 GUARDRAIL BOX 3 of 4 END CAPS (Left + Right) LONG RAILS TWIN SLAT KIT BOX 4 of 4 2 SET WINDSOR BUNK BED 09292009 Page 3 of 7... - Page 4 Attach the full guard rail (04) to the end caps (06), using JCB M6 X 2” (B), and barrel nut (C). Tighten with the Allen wrench (F). Repeat for 3/4 guard rail (05). WINDSOR BUNK BED 09292009 Page 4 of 7...
- Page 5 1 “ Wood Screw Customer Supplied Phillips head screwdriver Install the full and 3/4 guard rail assemblies onto the long rails, and fix in place using wood screws (D). Tighten with the Phillips head screwdriver. WINDSOR BUNK BED 09292009 Page 5 of 7...
- Page 6 Lay the twin slat kit (08) onto the bed, and fix in place using wood screws provided in the slat kit box. FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit. WINDSOR BUNK BED 09292009 Page 6 of 7...
- Page 7 FOLLOW ASSEMBLY INSTRUCTIONS INCLUDED WITH YOUR LADDER. Congratulations ! Your Windsor bunk bed is now ready for use. We recommend that you recheck that all screws are tightened, and that all parts are secure before use and periodically to ensure safety.
