Zaxcom ZMT3-HM

Time Left on Card

This menu will only appear if a card was inserted prior to booting up
TIME LEFT 20 H
TIME USED 4 H
This page displays the remaining record time left on the card as well as the time already recorded on the
card.

Automatic Record after Boot up

RECORD ON BOOTUP
OFF
Record on boot up allows the onboard recorder to automatically start recording after the ZMT3-HM boots
up.
ON - The onboard recorder will automatically start to record after the ZMT3-HM boots up.
•
OFF - The onboard recorder will wait for a ZaxNet command or a manual record trigger to start
•
recording.

Recording Mode Set

RECORD MODE:
LOOP RECORD
Record mode sets what the recorder will do after the card is full. Regardless of this setting the card can only
record 500 files.
NON-LOOP RECORD - Once the card is full the recording will stop and FULL will be displayed. This setting
•
prevents over-writing any portion of the audio.
LOOP RECORD - Once the card is full, the new audio will begin over-writing the oldest audio on the card.
•

Low Battery Stop Set

LOW BATT STOP:
NEVER STOP
Low battery stop will set the amount of time, after a low battery warning occurs, the on-board recorder will
close the current file and stop recording.
This is to prevent possible file corruption if the unit constantly powers off and on due to a dead battery.
NEVER STOP - The onboard recorder will not stop recording unless it is manually stopped by a key
•
press, or when it receives a stop command via ZaxNet, or if the battery dies.
Any interval from 1 to 99 minutes - Once the battery indicator starts blink a low battery warning the
•
onboard recorder will continue to record for the time set here - then it will close the file and stop
recording.
13
Record Menu
