RECORD MENU

SD Card Format

This menu will only appear if a card was inserted prior to booting up
PRESS UP KEY 5X:
TO ERASE CARD
The Micro SD card is erased and formatted from this menu. Please note that all cards need to be formatted
in the ZMT3-HM prior to recording.
Before formatting the card, the transmitter can optionally be renamed (see set up menu). When a
transmitter is named that name is included in the recorded file names. By naming the transmitter it makes
it easier to differentiate files from different recorders, so for example the card can be identified with the
talents name, or any other unique identifier. The card name menu is located at the end of the set up menu.
The factory default name is the transmitter's serial number.
Partial Format
If the card's FAT32 file structure gets corrupt while doing a file transfer, and the card is no longer
recognized by the transmitter or by ZaxConvert, a partial format can be done. The partial format rewrites
the FAT32 file structure and leaves the recorded audio untouched. To do a partial format from this menu
press the DEC key 9 times "PARTIAL FORMAT" will then be displayed.

Playback Control

STOP 09:18:05:02
SEG 001
Recorded files can be played back from this page.
The top line displays the current mode of the recorder: REC, PLAY or STOP followed by the time code.
The bottom line contains the current segment number and the audio level.
Playing back from the transport page:
Pressing the INC key while stopped will play the segment number that is displayed.
•
Pressing the DEC key while playing back will stop the playback.
•
Pressing the DEC key while stopped will jump back.
•
Holding the INC key will jump ahead one segment.
•
Holding the DEC key will jump back one segment.
•
Pressing the INC key while in play mode will cause the playback to jump ahead, repeated quick presses
•
will cause playback to advance in larger increments.
