Simrad R5000 Quick Manual

O5000 trackball keys
D
C
B
Cursor
Left key (B)
over...
Menu Select
Quick access
Select
button
AIS target Activate/deactivate
Radar target Acquire target
02000 front controls
¼ Note: The O2000 can be used with different equipment. Keys labelled with an asterisk (*) are not used for the R5000.
B C D E F
A
ABC DEF
GHI JKL MNO
S
PQRS TUV WXYZ
STANDBY
C
R Q P O
M5000 monitor keys
- +
ON/OFF BRILL ENTER
A B C D
R5000 Radar system
The optical trackball (A) is used for positioning the cursor.
The other trackball keys have different functionality depending on cursor position on the radar
panel.
A
The table lists the key functions relative to what part of the radar panel that is under the cursor.
¼ Note: The cursor must be located over an open menu or over the quick access pop-up to be
able to use the scroll function.
Right key (C)
Return to previous menu level
Display selected button's pop-up
Display target menu
G H I J
K
N M L
MENU
E
Quick Guide
A
Mark/MOB key *
B
Unit under command LEDs *
C
Display key*
D
EBL/VRM key
E
Trails key
F
Range key
G
Offset key
H
Enter key
I
Rotary knob
J
Exit key
A Power key
B
Brilliance adjustment key
C
Enter key
D
Red LED
E
Menu key
Scroll wheel (D)
•
Rotate to scroll menu options
•
Press to select
•
Rotate to scroll pop-up options
No action
K
Arrow keys
L
View key
M
Menu key
N
GAIN, SEA and RAIN keys
O
Acknowledge key
P
AIS key
Q
Standby/Brilliance key
R
Mode key *
S
Alpha numeric keypad
EN
