Philio PAD02 Quick Start Manual

PAD02 Z-Wave Smart Dimmer Socket
Introduction
PAD02 is an E27(EU)/ E26(US) Edison screw based lamp socket, which provides
electrical connection to the E14(EU)/ E12(US) Edison screw based lamps and
support it in the lighting fixture. The use of socket allows lamps to be safely and
conveniently replaced. You can On/Off the light by pressing the button briefly,
or a long pressing to control the brightness of dimmable lighbulb.
This dimmer is a transceiver which is a security enabled device which based on
Z-Wave Plus technology. Z-Wave Plus
TM
Plus logo can also be used with it regardless of the manufacturer, and can also be
used in other manufacturer's Z- Wave
of the connected light is possible with other manufacturer's wireless Controller.
Since PAD02 supports Security Command Class, it can learn with a Secured enabled
controller to fully utilize the device. Its functionality and supported command classes is
identical when included as a secure and non-secure device.
TM
enabled devices displaying the Z-Wave
TM enabled networks. Remote dim level control
Warning:
1. Plug out to disconnect from power supply; Do not plug in line.
2. For continued protection against risk of electric, replace only with same type and
rating of fuse.
3. Do not connect any appliances other than luminary products.
4. Do not connect any appliances to this remote controlled lampholder which are
radiating heat and may cause ignition or burning of surrounding materials (for
example radiation heaters, portable heaters, portable floodlights, desk lamps, etc).
5. Take into consideration that connected appliances might be moved by pets,
cleaning staff or other persons who are not aware of the remote control functions.
6. The connection/installation of this product should be in a suitable area with the
remote controlled lampholder easily readable and accessible for disconnection
actions.
Specification
Operating Voltage 220/ 230/ 240VAC 50/60Hz for EU
120VAC 60Hz for US
Maximum Load (Wattage) Max. 15 W Type B (for incandescent lamps)
Max.9W Type Dimmable SBLED
Built-in High Breaking Capacity Current Fuse Protection.
Fuse information
Rated: 1.25A; 250V
Built-in Thermal Cut-off Fuses Protection.
Rated Temperature: 125° C; Rated: 2A 250V
Screw lampholder Type: EU type: E27 to E14; PAD02-1
US type: E26 to E12; PAD02-2
Range Minimum 40m indoor 100m outdoor line of sight
Location Indoor used
Operating Temperature 0° C to 40° C
Frequency Range 868.40MHz & 869.85MHz/ EU (PAD02-1);
908.4MHz & 916.0MHz/ USA (PAD02-2);
RF Maximum Power +5dBm
FCCID RHHPAD02
** Specifications are subject to change and improvement without notice.
