I N S T R U C T I O N S P E R T A I N I N G T O A R I S K O F F I R E , E L E C T R I C S H O C K , O R I N J U R Y T O P E R S O N S
Important Safety Instructions. Save These Instructions.
WARNING: When using electronic products, basic precautions should always be followed, including:
1. Keep these instructions.
2. Heed all warnings.
3. Follow all instructions.
4. Do not use this apparatus near water.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
7. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
8. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
FCC Statement
FCC Compliance and Advisory Statement: This hardware device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions: 1) this device may not cause harmful interfer-
ence, and 2) this device must accept any interference received including interference that may cause
undesired operation. This equipment has been tested and found to comply with the limits for a Class
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
DO NOT REMOVE THE COVER (OR BACK).
protection against harmful interference in a commercial installation. This equipment generates, uses,
NO USER SERVICABLE PARTS INSIDE.
and can radiate radio frequency energy and, if not installed or used in accordance with the instructions,
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
may cause harmful interference to radio communications. However there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is
The lightning flash with arrowhead symbol, within an
encouraged to try to correct the interference by one or more of the following measures: 1) reorient or
equilateral triangle, is intended to alert the user to the
relocate the receiving antenna; 2) increase the separation between the equipment and the receiver; 3)
presence of uninsulated "dangerous voltage" with-
in the product's enclosure that may be of sufficient
connect the equipment to an outlet on a circuit different from that to which the receiver is connected;
magnitude to constitute a risk to persons.
4) consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not
expressly approved by the party responsible for compliance could void the user's authority to operate
The exclamation point within an equilateral triangle is
the equipment. Where shielded interface cables have been provided with the product or specified ad-
intended to alert the user to the presence of important
ditional components or accessories elsewhere defined to be used with the installation of the product,
operating and maintenance (servicing) instructions in
they must be used in order to ensure compliance with FCC regulations.
the literature accompanying the product.
|
Pa ge 2
H D br i dg e 25 0 0 / 2 6 0 0 -E U Co n fi g u ra tio n Gu id e
9. Power cord must be accessible to allow for the removal of power
from the unit.
10. Protect the power cord from being walked on or pinched, particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. Unplug the apparatus during lightning storms or when unused for
long periods of time.
12. Only use attachments/accessories specified by the manufacturer.
13. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
14. WARNING: To reduce the risk of fire or electric shock do not
place this apparatus in a position where it is exposed to dripping
or splashing liquids, rain, moisture, or excessively high humidity.
Objects containing liquid shall not be placed in proximity to the unit
such that they present a risk of spillage onto the apparatus.
w ww.z eev ee.c om
Welcome to ZeeVee.
ZeeVee products convert your video and audio source to
a digital cable channel and broadcast it over coax to all
your HDTVs. This guide walks you through basic and more
enhanced setup for ZeeVee's HDbridge 2500/2600 Series
modulators.
For support, repairs, and warranty service contact the
distributor where you purchased the product. For additional
questions call +1(877) 4-ZEEVEE (1.877.493.3833).
What's in the Box
Here's what you can expect to find when you open the package:
ZeeVee Modulator
Hydra Audio/Video Cables
x2 with HDb2620 and HDb2520
x4 with HDb2640 and HDb2540
Available Separately
Power Cord
Table of Contents
Front and Back Panels . . . . 4
Basic Installation . . . . . . . . 5
Beginning setup . . . . . . . . . . . . . . 5
the HDTV (Auto Scan) . . . . . . . . . . 5
channels or power . . . . . . . . . . . . 6
CCIR Table vs Frequency Map . . . 7
Maestro Configuration . . 8-9
Connecting with Maestro . . . . . . . 8
Configuring RF numbers
and virtual channels . . . . . . . . . . . 8
and content information . . . . . . . . 8
Using other Maestro tabs . . . . . . . 9
Troubleshooting . . . . . . . 10
Warranty . . . . . . . . . . . . . 11
Contact ZeeVee . . . . . . . . 12
|
H D br id ge 2 50 0/ 2 6 00 -E U Co n f ig u ra t io n Gu id e
Pa g e 3
